272-5996 LINES GP-AIR CONDITIONERS/N JJM1-UP

Group No: 272-5996

Part Number	Part Name	Qty
7I2673	1 STRAP-CABLE	1
7K1181	2 STRAP-CABLE	7
1761902	3 DRYER AS-REFRIGERANT (RECEIVER)	1
1849336	4 SUPPORT	1
1893434	5 ELBOW	1
2359014	6 CLAMP-SPRING	2
3276549	7 HOSE AS	1
1217137	SEAL-O-RING	2
2457850	PLUG	1
2457928	8 HOSE AS	1
1217138	SEAL-O-RING	2
2783486	9 HOSE AS	1
1217138	SEAL-O-RING	2
2783487	10 HOSE AS	1
1217136	SEAL-O-RING	1
2457851	PLUG	1
1043173	11 CLIP	4
1158645	12 GUARD	2
1217098	13 BRACKET AS	1
8T4138	BOLT (M6X1X20-MM)	2
9X8256	WASHER (6.6X12X2-MM THK)	2
2041673	14 STRAP-CABLE	1
3K0360	15 SEAL-O-RING	3
4I6039	16 GROMMET	1
6V3378	17 CLIP	3
6V7238	18 VALVE-SHUTOFF	2
6V7357	19 BOLT (M6X1X25-MM)	4
7Y8165	20 GROMMET	1
1334419	21 GROMMET	1
8M2773	22 CLIP (LOOP)	6
8T4121	23 WASHER-HARD (11X21X2.5-MM THK)	14
8T4137	24 BOLT (M10X1.5X20-MM)	12
8T4200	25 BOLT (M8X1.25X16-MM)	2
8T4224	26 WASHER-HARD (8.8X16X2-MM THK)	2
8T4971	27 BOLT (M6X1X30-MM)	2
9X8256	28 WASHER (6.6X12X2-MM THK)	6
5P0767	29 HOSE (465-CM)
5P0767	29A HOSE (505-CM)
3S8536	30 SPACER (0.406X0.656X0.38-IN THK)	1
8B6561	31 SPACER (5.56X22.22X55.58-MM THK)	1
8T4172	32 BOLT (M10X1.5X80-MM)	1
8T4195	33 BOLT (M10X1.5X30-MM)	1
2735428	34 GUARD	1
2931135	35 GUARD (15-CM)
3276548	36 TUBE AS	1
1217137	SEAL-O-RING	1
1158929	37 GUARD	2
