Assembly
100%

551-4730 FRAME AS-UPPERS/N XBE1-UP

Group No: 551-4730
Part NumberPart NameQty
55147311 FRAME AS-MAIN1
7Y2318BOSS2
8Y3795BOSS (M10X1.5X40-MM)2
9R2672BOSS-THREADED (M10X1.5X20-MM)1
9R4941BOSS1
8T3490NUT-WELD (M10X1.5-THD)2
17870232 BOSS (M10X1.5X30-MM)1
7Y06333 BOSS (1/8-27X.375-IN)1
7Y62154 PLATE2
8Y37955 BOSS (M10X1.5X40-MM)8
9R21606 BOSS (M8X1.25X25-MM)1
9R26727 BOSS-THREADED (M10X1.5X20-MM)5
50632408 BOSS AS3
8Y3925BOSS (M10X1.5X30-MM)1
55147639 SUPPORT AS1
2670114PLATE AS1
551475810 SUPPORT AS1
8Y3795BOSS (M10X1.5X40-MM)1
9R2672BOSS-THREADED (M10X1.5X20-MM)1
2670114PLATE AS1
8T3597NUT-WELD (M12X1.75-THD)1
8T3597NUT-WELD (M12X1.75-THD)1
551473211 FRAME AS1
8Y3795BOSS (M10X1.5X40-MM)2
9R2672BOSS-THREADED (M10X1.5X20-MM)6
1787023BOSS (M10X1.5X30-MM)4
8T3597NUT-WELD (M12X1.75-THD)2
551473312 FRAME AS1
7Y6215PLATE2
9R2672BOSS-THREADED (M10X1.5X20-MM)3
1780711BLOCK-MOUNTING2
1787023BOSS (M10X1.5X30-MM)4
8T3490NUT-WELD (M10X1.5-THD)7
8T3597NUT-WELD (M12X1.75-THD)6
551475013 SUPPORT AS1
7Y6215PLATE1
