System And Components
562-4559 LINES GP-PUMP -MEDIUM PRESSURES/N XBE1-UP
Group No: 562-4559
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1837121 | 1 BOLT (M10X1.5X35-MM) | 4 | |
| 7X2543 | 2 BOLT (M10X1.5X120-MM) | 4 | |
| 8T4198 | 3 BOLT (M10X1.5X100-MM) | 4 | |
| 8T4648 | 4 BOLT (M12X1.75X70-MM) | 2 | |
| 3100165 | 5 VALVE GP-CONTROL (MEDIUM PRESSURE, PUMP RELIEF) | 1 | |
| 1017198 | 6 ADAPTER | 1 | |
| 1068715 | 7 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 8C8400 | ELBOW | 1 | |
| 1358573 | 8 BOLT AS | 2 | |
| 1488347 | 9 ELBOW AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9007 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1645567 | 10 COUPLER AS-QUICK DISCONNECT (MALE) | 2 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1645608 | 11 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T1687 | CONNECTOR | 1 | |
| 1648908 | 12 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T0077 | CONNECTOR | 1 | |
| 2866499 | 13 CONNECTOR AS | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1849330 | CONNECTOR | 1 | |
| 3664695 | 14 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 3603679 | PLUG-CONNECTOR (9/16-18-THD) | 1 | |
| 5428512 | 15 BLOCK | 1 | |
| 5434638 | 16 BLOCK | 1 | |
| 5680719 | 17 SUPPORT AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 2686910 | SPACER (14X25X45-MM THK) | 2 | |
| 5680721 | 18 HOSE AS | 1 | |
| 5680724 | 19 HOSE AS | 1 | |
| 5680727 | 20 HOSE AS | 1 | |
| 1P3703 | 21 SEAL-RECTANGULAR | 1 | |
| 1P4578 | 22 FLANGE-HALF | 2 | |
| 4J0522 | 23 SEAL-O-RING | 3 | |
| 4K1388 | 24 SEAL-O-RING | 1 | |
| 6V0852 | 25 CAP-DUST | 2 | |
| 8T4121 | 26 WASHER-HARD (11X21X2.5-MM THK) | 16 | |
| 8T4136 | 27 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4223 | 28 WASHER-HARD (13.5X25.5X3-MM THK) | 2 |
