560-9529 LINES GP-AIR CONDITIONER -R-134AS/N XBE1-UP

Group No: 560-9529

Part Number	Part Name	Qty
8T4182	1 BOLT (M10X1.5X45-MM)	1
8T4189	2 BOLT (M8X1.25X20-MM)	2
8T4200	3 BOLT (M8X1.25X16-MM)	2
0672551	4 CLIP	1
1004336	5 CLIP (LOOP)	1
1217098	6 BRACKET AS	1
8T4138	BOLT (M6X1X20-MM)	2
9X8256	WASHER (6.6X12X2-MM THK)	2
1229657	7 CLAMP	2
1761902	8 DRYER AS-REFRIGERANT (RECEIVER)	1
2041611	9 STRAP-CABLE (DUAL)	1
2358891	10 PLATE	1
2359014	11 CLAMP-SPRING	4
2378510	12 GROMMET	1
3050441	13 BAND-MARKER (HS)	2
3050442	14 BAND-MARKER (HR)	2
4741553	15 ADAPTER	1
4837800	16 SPACER (11X20X20-MM THK)	1
4841456	17 STRAP-CABLE	6
5609517	18 PIPE AS	1
1217138	SEAL-O-RING	2
5609518	19 HOSE AS	1
1217138	SEAL-O-RING	2
1300270	SWITCH AS-PRESSURE (REFRIGERANT)	1
1858293	SEAL-O-RING	1
5609519	20 HOSE AS	1
1217136	SEAL-O-RING	2
5609520	21 HOSE AS	1
1217136	SEAL-O-RING	1
2457851	CAP	1
5609521	22 HOSE AS	1
1217137	SEAL-O-RING	2
5609522	23 HOSE AS	1
1217137	SEAL-O-RING	1
2457850	CAP	1
5609526	24 BRACKET AS	1
8T3490	NUT-WELD (M10X1.5-THD)	1
5609528	25 CONDENSER & MTG GP-REFRIGERANT	1
5758715	26 BRACKET AS	1
8T3490	NUT-WELD (M10X1.5-THD)	2
5758716	27 BRACKET AS	1
8T3490	NUT-WELD (M10X1.5-THD)	2
8Y3795	BOSS (M10X1.5X40-MM)	1
5767680	28 PLATE & FILM GP (AIR CONDITIONER)	1
5P9297	29 CLIP (LOOP)	1
5P9299	30 CLIP (LOOP)	1
6D1641	31 CLIP (LOOP)	3
6D3479	32 CLIP (LOOP)	2
6V2235	33 CLIP	5
6V7357	34 BOLT (M6X1X25-MM)	4
7K1181	35 STRAP-CABLE	1
8T4121	36 WASHER-HARD (11X21X2.5-MM THK)	18
8T4137	37 BOLT (M10X1.5X20-MM)	17
8T4224	38 WASHER-HARD (8.8X16X2-MM THK)	6
8T4971	39 BOLT (M6X1X30-MM)	1
8T7547	40 BOLT (M8X1.25X30-MM)	2
9X8256	41 WASHER (6.6X12X2-MM THK)	5
5P0767	43 HOSE (385-CM)
5P0767	43A HOSE (370-CM)
1613718	44 HOSE-DRAIN	2
