System And Components
381-2171 LINES GP-FRONT -UNIVERSAL QUICK COUPLERS/N YEP295-UP; BZY1205-UP
Group No: 381-2171 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I7889 | 1 SPACER (11X25X45-MM THK) | 1 | |
| 4I9528 | 2 BAND-MARKER (PURPLE, R4) | 2 | |
| 5P5148 | 3 STRAP-CABLE | 2 | |
| 6V0852 | 4 CAP-DUST | 3 | |
| 7K1181 | 5 STRAP-CABLE | 12 | |
| 7Y8379 | 6 HOSE AS | 1 | |
| 7Y8478 | 7 HOSE AS | 1 | |
| 1110985 | 8 HOSE AS | 1 | |
| 1234750 | 9 VALVE AS-CHECK | 1 | |
| 1488420 | 10 TEE AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T6338 | TEE-O-RING PORT | 1 | |
| 1504027 | 11 TEE AS | 1 | |
| 3E2310 | TEE | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1681968 | 12 TEE AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1266872 | TEE | 1 | |
| 2586749 | 13 VALVE GP-SOLENOID (QUICK COUPLER) | 1 | |
| 2751442 | 14 CLIP (TAB) | 1 | |
| 2751443 | 15 CLIP (SLOT) | 1 | |
| 2751818 | 16 HOSE AS | 1 | |
| 2786618 | 17 HOSE AS | 1 | |
| 2967317 | 18 HOSE AS | 1 | |
| 3237894 | 19 VALVE GP-SOLENOID & PRESS REDC (BOOM LOWERING CONTROL) | 1 | |
| 3334609 | 20 GROMMET | 1 | |
| 3337097 | 21 HOSE AS | 1 | |
| 3386970 | 22 SENSOR GP-PRESSURE (STICK IN) | 1 | |
| 3394353 | 23 VALVE GP-CONTROL (QUICK COUPLER) | 1 | |
| 3515059 | 24 SUPPORT AS | 1 | |
| 3698367 | 25 VALVE GP-CHECK (SLOW RETURN)(SLOW RETURN, STICK IN, BOOM UP) | 1 | |
| 3618918 | 26 HOSE AS | 1 | |
| 3660926 | 27 HOSE AS | 1 | |
| 3660929 | 28 HOSE AS | 1 | |
| 3710128 | 29 HOSE AS | 1 | |
| 3739999 | 30 HOSE AS | 1 | |
| 3839558 | 31 HOSE AS | 1 | |
| 3839559 | 32 SUPPORT AS | 1 | |
| 3853039 | 33 HOSE AS | 1 | |
| 1048903 | 34 GUARD | 1 | |
| 1488336 | 35 CONNECTOR AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488353 | 36 ELBOW AS | 3 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9001 | ELBOW | 1 | |
| 1488367 | 37 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9850 | ELBOW | 1 | |
| 1488378 | 38 ELBOW AS | 8 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1488407 | 39 PLUG AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 1488435 | 40 TEE AS | 3 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8781 | TEE | 1 | |
| 1488439 | 41 TEE AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8774 | TEE | 1 | |
| 1503036 | 42 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T1905 | ELBOW | 1 | |
| 1645546 | 43 TEE AS | 2 | |
| 3E7410 | TEE | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1645567 | 44 COUPLER AS-QUICK DISCONNECT (MALE) | 3 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1646874 | 45 FITTING AS-ELBOW (QUICK DISCONNECT, MALE) | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 0857356 | ELBOW-ADAPTER | 1 | |
| 1942903 | 46 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 8T0119 | ELBOW | 1 | |
| 4I9521 | 48 BAND-MARKER (RED, L1) | 4 | |
| 4I9522 | 49 BAND-MARKER (YELLOW, L2) | 6 | |
| 4I9523 | 50 BAND-MARKER (BLUE, L3) | 6 | |
| 4I9525 | 51 BAND-MARKER (ORANGE, R1) | 2 | |
| 8T3647 | 53 BOLT (M8X1.25X80-MM) | 4 | |
| 8T4121 | 54 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4136 | 55 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4137 | 56 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4139 | 57 BOLT (M12X1.75X30-MM) | 2 | |
| 8T4177 | 58 BOLT (M8X1.25X90-MM) | 3 | |
| 8T4223 | 59 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4224 | 60 WASHER-HARD (8.8X16X2-MM THK) | 7 | |
| 8T5005 | 61 BOLT (M10X1.5X70-MM) | 1 |
