System And Components
332-9661 LINES GP-AUXILIARY HYDRAULIC -STICK, HIGH PRESSURES/N SD21-UP
Group No: 332-9661
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1426583 | 1 TUBE AS | 1 | |
| 3892407 | 2 VALVE GP-MANUAL (AUXILIARY, SHUTOFF, 2-WAY FLOW) | 1 | |
| 4420234 | 3 VALVE AS-BALL | 1 | |
| 2946485 | 4 TUBE AS | 1 | |
| 3061354 | 5 CLAMP-HALF | 4 | |
| 3061355 | 6 CLAMP-HALF | 4 | |
| 3568021 | 7 HOSE AS | 1 | |
| 3568084 | 8 HOSE AS | 1 | |
| 4532836 | 9 BOLT (M16X2X45-MM) | 8 | |
| 1P3704 | 10 SEAL-RECTANGULAR | 3 | |
| 1P3705 | 11 SEAL-RECTANGULAR | 3 | |
| 1P5767 | 12 FLANGE-HALF | 4 | |
| 5P8077 | 13 FLANGE-HALF | 4 | |
| 4532840 | 14 BOLT (M16X2X140-MM) | 2 | |
| 8T4121 | 15 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 4471707 | 16 BOLT (M16X2X60-MM) | 8 | |
| 8T4183 | 17 BOLT (M12X1.75X40-MM) | 4 | |
| 4471711 | 18 BOLT (M16X2X50-MM) | 4 | |
| 8T4194 | 19 BOLT (M12X1.75X50-MM) | 8 | |
| 8T4223 | 20 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T6685 | 21 BOLT (M10X1.5X110-MM) | 2 | |
| 4512175 | 22 WASHER-HARD (17.5X30X3.5-MM THK) | 22 | |
| 7X0584 | 23 WASHER-HARD (13.5X20.5X2-MM THK) | 4 |
