System And Components
458-8255 LINES GP-BOOMS/N SD21-UP
Group No: 458-8255
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9F2167 | 1 SCREW-PURGE (3/8-24X1.164-IN) | 4 | |
| 1241107 | 2 GROMMET | 3 | |
| 1295874 | 3 GROMMET | 14 | |
| 1385709 | 4 GROMMET | 3 | |
| 1991875 | 5 GROMMET | 2 | |
| 2489835 | 6 TUBE AS | 1 | |
| 2489836 | 7 TUBE AS | 1 | |
| 2895678 | 8 TUBE AS | 2 | |
| 3515047 | 9 HOSE AS | 1 | |
| 3515048 | 10 HOSE AS | 1 | |
| 4471707 | 11 BOLT (M16X2X60-MM) | 8 | |
| 4471709 | 12 BOLT (M16X2X45-MM) | 2 | |
| 4512175 | 13 WASHER-HARD (17.5X30X3.5-MM THK) | 20 | |
| 4532838 | 14 BOLT (M16X2X70-MM) | 10 | |
| 4602567 | 15 TUBE AS | 1 | |
| 4602568 | 16 TUBE AS | 1 | |
| 4602569 | 17 TUBE AS | 1 | |
| 4602570 | 18 TUBE AS | 1 | |
| 0969986 | 19 BOLT (M12X1.75X55-MM) | 20 | |
| 1241108 | 20 CLIP | 28 | |
| 1385708 | 21 CLIP-HALF | 8 | |
| 1960482 | 22 CLIP | 4 | |
| 1P3703 | 23 SEAL-RECTANGULAR | 4 | |
| 1P3704 | 24 SEAL-RECTANGULAR | 2 | |
| 1P3705 | 25 SEAL-RECTANGULAR | 2 | |
| 1P5767 | 26 FLANGE-HALF | 4 | |
| 5P8077 | 27 FLANGE-HALF | 4 | |
| 6H3615 | 28 PLUG-PROTECTION | 4 | |
| 8T4139 | 29 BOLT (M12X1.75X30-MM) | 16 | |
| 8T4194 | 30 BOLT (M12X1.75X50-MM) | 16 | |
| 8T4223 | 31 WASHER-HARD (13.5X25.5X3-MM THK) | 36 |
