System And Components
528-0097 LINES GP-BOOM -MASSS/N SD21-UP
Group No: 528-0097
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0969986 | 1 BOLT (M12X1.75X55-MM) | 20 | |
| 7X0584 | 2 WASHER-HARD (13.5X20.5X2-MM THK) | 16 | |
| 1P5767 | 3 FLANGE-HALF | 4 | |
| 5P8077 | 4 FLANGE-HALF | 4 | |
| 6H3615 | 5 PLUG-PROTECTION | 4 | |
| 8T4956 | 6 BOLT (M12X1.75X35-MM) | 16 | |
| 2489835 | 7 TUBE AS | 1 | |
| 2489836 | 8 TUBE AS | 1 | |
| 9F2167 | 9 SCREW-PURGE (3/8-24X1.164-IN) | 4 | |
| 2895678 | 10 TUBE AS | 2 | |
| 1241107 | 11 GROMMET | 3 | |
| 3515047 | 12 HOSE AS | 1 | |
| 1295874 | 13 GROMMET | 16 | |
| 1385708 | 14 CLIP-HALF | 8 | |
| 1385709 | 15 GROMMET | 3 | |
| 1960482 | 16 CLIP | 4 | |
| 3515048 | 17 HOSE AS | 1 | |
| 4471707 | 18 BOLT (M16X2X60-MM) | 8 | |
| 4471709 | 19 BOLT (M16X2X45-MM) | 2 | |
| 4512175 | 20 WASHER-HARD (17.5X30X3.5-MM THK) | 20 | |
| 4532838 | 21 BOLT (M16X2X70-MM) | 10 | |
| 4602567 | 22 TUBE AS | 1 | |
| 4602568 | 23 TUBE AS | 1 | |
| 4602569 | 24 TUBE AS | 1 | |
| 4602570 | 25 TUBE AS | 1 | |
| 1241108 | 26 CLIP | 28 | |
| 1P3703 | 27 SEAL-RECTANGULAR | 4 | |
| 1P3704 | 28 SEAL-RECTANGULAR | 2 | |
| 1P3705 | 29 SEAL-RECTANGULAR | 2 | |
| 8T4194 | 30 BOLT (M12X1.75X50-MM) | 16 | |
| 8T4223 | 31 WASHER-HARD (13.5X25.5X3-MM THK) | 36 |
