System And Components
227-6145 GEAR & BEARING GP-SWINGS/N MBP1-UP
Group No: 227-6145 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2B7561 | 1 CORK | 2 | |
| 5K9243 | 2 ELBOW-FLARED | 4 | |
| 7Y1507 | 3 SPACER (24.5X44X43-MM THK) | 46 | |
| 7Y1647 | 4 GASKET | 1 | |
| 7Y1650 | 5 CLAMP-HOSE | 1 | |
| 1994523 | 6 TUBE AS (RH) | 1 | |
| 1994524 | 7 TUBE AS (LH) | 1 | |
| 3530487 | 8 GEAR & BEARING GP-SWING | 1 | |
| 2276105 | 9 BOOT | 1 | |
| 2276106 | 10 RETAINER | 1 | |
| 1416373 | 11 BOLT (M24X3X150-MM) | 42 | |
| 1121531 | 12 BOLT (M24X3X120-MM) | 46 | |
| 1484703 | 13 COVER | 1 | |
| 1484704 | 14 GASKET | 1 | |
| 3B8489 | 15 ADAPTER (1/8-27 PTF) | 2 | |
| 4N9170 | 16 CLIP | 4 | |
| 7Y1095 | 17 DOWEL | 1 | |
| 7Y1648 | 18 STRIP | 1 | |
| 4533454 | 19 WASHER-HARD (11X21X2.5-MM THK) | 14 | |
| 4553798 | 20 BOLT (M10X1.5X25-MM) | 12 | |
| 0930020 | 21 SPACER (25X44X6-MM THK) | 42 | |
| 8T4199 | 22 BOLT (M8X1.25X12-MM) | 4 | |
| 4578759 | 24 BOLT (M10X1.5X20-MM) | 2 | |
| 1U8846 | SEALANT-GASKET |
