System And Components
484-7948 GEAR & BEARING GP-SWINGS/N B381-UP
Group No: 484-7948
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B8489 | 1 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 5K9243 | 2 ELBOW-FLARED | 4 | |
| 6I6441 | 3 CORK | 17 | |
| 7Y1647 | 4 GASKET | 1 | |
| 1484573 | 5 PLUG | 1 | |
| 2276105 | 6 BOOT | 1 | |
| 2276106 | 7 RETAINER | 1 | |
| 3333044 | 8 GEAR & BEARING GP-SWING | 1 | |
| 3B8489 | FITTING-GREASE (1/8-27 PTF) | 1 | |
| 1484685 | SEAL (469-CM) | ||
| 2276075 | SEAL-DUST | 2 | |
| 3333081 | 9 TUBE AS (LH) | 1 | |
| 3333084 | 10 TUBE AS (RH) | 1 | |
| 0930020 | 11 SPACER (25X44X6-MM THK) | 54 | |
| 4613889 | 12 BOLT (M24X3X160-MM) | 54 | |
| 1484703 | 13 COVER | 1 | |
| 1484704 | 14 GASKET | 1 | |
| 4N9170 | 15 CLIP | 4 | |
| 7Y1095 | 16 DOWEL | 1 | |
| 7Y1648 | 17 STRIP | 1 | |
| 7Y1650 | 18 CLAMP-HOSE | 1 | |
| 8T4121 | 19 WASHER-HARD (11X21X2.5-MM THK) | 14 | |
| 8T4136 | 20 BOLT (M10X1.5X25-MM) | 12 | |
| 8T4137 | 21 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4199 | 22 BOLT (M8X1.25X12-MM) | 4 | |
| 1U8846 | SEALANT-GASKET |
