System And Components
482-6619 DRIVE GP-SWING -WITHOUT MOTORS/N GDY1-UP
Group No: 482-6619
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4H6112 | 1 BREATHER (SWING DRIVE) | 1 | |
| 6V7238 | 2 VALVE-SHUTOFF (SWING DRIVE) | 1 | |
| 7Y1100 | 3 BEARING-ROLLER | 1 | |
| 0941528 | 4 WASHER (53X84X1-MM THK) | 6 | |
| 1107149 | 5 RING-RETAINING | 1 | |
| 1141322 | 6 RING-RETAINING | 1 | |
| 1141398 | 7 GAUGE-OIL LEVEL (SWING DRIVE) | 1 | |
| 1141399 | 8 PIPE-GAUGE | 1 | |
| 1484605 | 9 SHAFT-PINION | 1 | |
| 2276215 | 10 BOSS (1/4-18-THD) | 1 | |
| 3789524 | 11 SHAFT | 4 | |
| 3789525 | 12 WASHER (62.3X104X1-MM THK) | 8 | |
| 3789526 | 13 GEAR-RING (67-TEETH) | 1 | |
| 3789527 | 14 GEAR-PLANETARY (24-TEETH) | 4 | |
| 2966269 | 15 BEARING-ROLLER | 3 | |
| 4531671 | 16 CARRIER-PLANETARY | 1 | |
| 3789528 | 17 GEAR-PLANETARY (24-TEETH) | 3 | |
| 3789529 | 18 GEAR-SUN (13-TEETH) | 1 | |
| 3789530 | 19 GEAR-SUN (17-TEETH) | 1 | |
| 3789531 | 20 CARRIER AS | 1 | |
| 3789560 | 21 COVER-HOUSING | 1 | |
| 4512175 | 22 WASHER-HARD (17.5X30X3.5-MM THK) | 24 | |
| 4512182 | 23 WASHER-HARD (13.5X25.5X3-MM THK) | 24 | |
| 4533447 | 24 BOLT (M12X1.75X40-MM) | 22 | |
| 4814229 | 25 HOUSING | 1 | |
| 4814230 | 26 CAGE | 1 | |
| 4814232 | 27 BEARING | 1 | |
| 5065904 | 28 SPACER | 1 | |
| 5101989 | 29 PIN-SPRING | 4 | |
| 5445577 | 30 HOSE AS | 1 | |
| 0931730 | 31 RING-RETAINING | 1 | |
| 0950927 | 32 RING-RETAINING | 3 | |
| 0961441 | 33 RING-RETAINING | 1 | |
| 1289170 | 34 SEAL-LIP TYPE | 2 | |
| 1362803 | 35 CLIP | 2 | |
| 2H6340 | 36 SEAL-O-RING | 1 | |
| 3789593 | 37 BEARING AS | 8 | |
| 3K0360 | 38 SEAL-O-RING | 1 | |
| 7D5363 | 39 CONNECTOR (9/16-18-THD) | 2 | |
| 7I7684 | 40 SPACER (50X79.6X6-MM THK) | 2 | |
| 8T0348 | 41 BOLT-SOCKET HEAD (M16X2X50-MM) | 24 | |
| 8T4244 | 42 NUT (M12X1.75-THD) | 1 | |
| 4533446 | 43 BOLT (M12X1.75X35-MM) | 1 | |
| 1U8846 | SEALANT-GASKET |
