521-8024 LINKAGE GP-BUCKET -DB-FAMILY, WITH LIFTING EYES/N GDY1-UP

Group No: 521-8024
Part NumberPart NameQty
3B84891 FITTING-GREASE (1/8-27 PTF)5
09303492 WASHER (22X60X6-MM THK)1
16614883 SHIM (2-MM THK)2
16614964 SEAL-LIP TYPE4
20127715 WASHER (26X90X8-MM THK)1
20128366 BOLT (M24X3X200-MM)1
24171297 LINK1
25125528 PIN AS1
25125589 PIN AS1
451217610 WASHER-HARD (22X35X3.5-MM THK)1
451217711 WASHER-HARD (26X44X4-MM THK)1
451218412 NUT (M20X2.5-THD)2
451218513 NUT (M24X3-THD)2
453284514 BOLT (M20X2.5X40-MM)1
453285415 BOLT (M24X3X50-MM)1
504210716 LINK AS1
504210917 PIN1
504211018 PIN1
504211119 SPACER (72X135X22-MM THK)1
504211220 SPACER (102X195X22-MM THK)1
521802521 LINK & BEARING AS1
504763421A BEARING-SLEEVE2
489300821B BEARING-SLEEVE2
166149522 SEAL-LIP TYPE2
186564923 BOLT (M20X2.5X160-MM)1
367846824 SEAL-O-RING2
367846925 SEAL-O-RING2
