System And Components
487-6678 COVER GP-CABS/N GDY1-UP
Group No: 487-6678
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I4270 | 1 HOLDER-GLASS | 1 | |
| 1282135 | 2 SCREW-TRUSS HEAD (M6X1X13-MM) | 4 | |
| 1282136 | 3 SCREW-TRUSS HEAD (M6X1X16-MM) | 2 | |
| 1858205 | 4 CLIP | 4 | |
| 4876679 | 5 COVER AS-ACCESS | 1 | |
| 5115919 | CLIP | 6 | |
| 4876680 | 6 COVER AS-ACCESS | 1 | |
| 4876839 | RIVET | 6 | |
| 4876682 | 7 COVER AS-ACCESS | 1 | |
| 4876839 | RIVET | 5 | |
| 4876683 | 8 COVER AS-ACCESS | 1 | |
| 4876839 | RIVET | 3 | |
| 4876684 | 9 COVER | 1 | |
| 4876851 | 10 COVER | 1 | |
| 4876955 | 11 HOOK | 2 | |
| 4886484 | 12 COVER AS-ACCESS | 1 | |
| 4876839 | RIVET | 2 | |
| 4886515 | 13 COVER AS-ACCESS | 1 | |
| 5115919 | CLIP | 8 | |
| 4886574 | 14 BRACKET AS | 1 | |
| 4886577 | 15 BRACKET AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 2 | |
| 4987709 | 16 COVER AS-ACCESS | 1 | |
| 4876839 | RIVET | 3 | |
| 5000730 | 17 HOLDER | 2 | |
| 5115900 | 18 COVER | 1 | |
| 5115901 | 19 COVER | 1 | |
| 5115972 | 20 INSULATION | 1 | |
| 5208287 | 21 PLUG | 2 | |
| 5268556 | 22 LINER | 2 | |
| 5268557 | 23 LINER | 4 | |
| 5268558 | 24 LINER | 6 | |
| 5268559 | 25 LINER | 4 | |
| 3E8020 | 26 SCREW-TRUSS HEAD (M6X1X25-MM) | 6 | |
| 9X2044 | 27 SCREW-TRUSS HEAD (M6X1X16-MM) | 5 | |
| 5268643 | 28 LINER | 1 | |
| 5268642 | 29 CLIP | 4 |
