System And Components
477-7567 PARTS GP-DOORS/N GDY1-UP
Group No: 477-7567
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I4286 | 1 KNOB | 1 | |
| 1858286 | 2 SCREW-MACHINE (M4X0.7X8-MM) | 2 | |
| 0963884 | 3 NUT-SPRING (M8X1.25-THD) | 2 | |
| 1018899 | 4 SCREW AS (M6X1.0X16-MM) | 2 | |
| 1018900 | 5 SCREW AS (M6X1X20-MM) | 2 | |
| 1519461 | 6 SPACER | 2 | |
| 1566643 | 7 COVER | 2 | |
| 5621642 | 8 HANDLE AS-DOOR | 1 | |
| 5599608 | HANDLE AS | 1 | |
| 5480043 | ROD-HANDLE | 1 | |
| 1640515 | 9 JOINT | 1 | |
| 1677039 | 10 GROMMET | 1 | |
| 1785573 | 11 SPACER | 3 | |
| 1785574 | 12 SPACER | 2 | |
| 1892690 | 13 HANDLE | 1 | |
| 3346526 | 14 SPACER | 2 | |
| 3346527 | 15 SPACER | 2 | |
| 3346538 | 16 BUSHING-RUBBER | 1 | |
| 4865461 | 17 GLASS | 1 | |
| 4865497 | 18 HANDLE AS | 1 | |
| 2014391 | CLIP | 1 | |
| 5327404 | 19 LOCK AS | 1 | |
| 1640514 | CLIP (10.5-MM) | 1 | |
| 1640519 | CLIP (13-MM) | 1 | |
| 4876775 | 20 COVER | 1 | |
| 4876776 | 21 COVER | 1 | |
| 4876782 | 22 COVER | 1 | |
| 4886548 | 23 SWITCH AS-CONTROL (CAB) | 1 | |
| 5208239 | 24 HOOK AS | 1 | |
| 5268628 | 25 PLUG | 3 | |
| 5327319 | 26 SEAL AS | 1 | |
| 5388843 | 27 WINDOW GP-DOOR | 1 | |
| 5389681 | 28 HANDLE-PULL | 1 | |
| 5389682 | 29 CAP | 2 | |
| 5390213 | 30 BRACKET AS | 1 | |
| 1091393 | 31 BOLT-SOCKET HEAD (M4X0.7X10-MM) | 1 | |
| 1858180 | 32 SCREW (M6X1X16-MM) | 3 | |
| 9X2042 | 33 SCREW-TRUSS HEAD (M6X1X12-MM) | 10 |
