System And Components
360-1591 LINES GP-FUEL FILTERS/N HRA1-1740; GLS1-UP
Group No: 360-1591 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P0436 | 1 GASKET (FUEL PRIMING PUMP) | 1 | |
| 3S2093 | 2 STRAP-CABLE | 6 | |
| 6Y1352 | 3 SPACER (10.5X20X27-MM THK) | 1 | |
| 7C8246 | 4 SPACER (10.5X20X24-MM THK) | 2 | |
| 8C2948 | 5 ADAPTER-TEE | 1 | |
| 9J6189 | 6 CLIP | 1 | |
| 1230783 | 7 VALVE GP-FLUID SAMPLING (FUEL) | 1 | |
| 1236948 | 8 PLUG | 1 | |
| 1375541 | 9 PUMP GP-FUEL PRIMING | 1 | |
| 2293218 | VALVE AS | 2 | |
| 1396873 | 10 VALVE GP-FUEL BYPASS (FILTER) | 1 | |
| 1759079 | 11 ROD-LINK | 1 | |
| 2336148 | 12 HOSE AS | 1 | |
| 2336742 | 13 VALVE GP-CHECK (FUEL) | 1 | |
| 2345013 | 14 SENSOR GP-TEMPERATURE | 1 | |
| 2353596 | 15 ADAPTER AS | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 2353595 | ADAPTER | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 2379314 | 16 BASE AS | 1 | |
| 9S4167 | STUD-HOLLOW (1-14X1.47-IN) | 1 | |
| 2475715 | 17 BRACKET | 1 | |
| 2591907 | 18 HOSE AS | 2 | |
| 2726668 | 19 HOSE AS | 1 | |
| 2746719 | 20 SENSOR GP-PRESSURE (3-PIN) | 1 | |
| 2788844 | 21 PLUG AS-CONNECTOR | 1 | |
| 8T8737 | PLUG-SEAL | 2 | |
| 2304011 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 2647029 | SEAL-CONNECTOR | 1 | |
| 3614675 | 22 HARNESS AS-SENSOR | 1 | |
| 1325789 | 23 CLIP (LADDER) | 1 | |
| 1833399 | 24 CONNECTOR AS | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 1833407 | 25 PLUG AS | 1 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1917805 | 26 ELBOW AS | 2 | |
| 0307947 | ADAPTER-ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2067337 | 27 TUBE AS | 1 | |
| 2147568 | 28 SEAL-O-RING | 1 | |
| 2287091 | 29 SEAL-O-RING | 1 | |
| 2385081 | 30 SEAL-O-RING | 2 | |
| 2Y5829 | 31 NUT (M10X1.5-THD) | 1 | |
| 3072673 | 32 PLUG AS | 2 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3139614 | 33 ADAPTER AS | 1 | |
| 2R6806 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3218671 | 34 CONNECTOR AS | 2 | |
| 0308188 | CONNECTOR | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3309765 | 35 TEE AS | 1 | |
| 1057704 | TEE | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3535102 | 36 FITTING AS-ELBOW | 1 | |
| 0054362 | ELBOW | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3535103 | 37 ADAPTER AS | 1 | |
| 0307942 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3E4352 | 38 WASHER-HARD (8.8X20.5X2.5-MM THK) | 1 | |
| 4P7581 | 39 CLIP (LADDER) | 2 | |
| 5P0537 | 40 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 6V6317 | 41 BOLT (M10X1.5X20-MM) | 1 | |
| 6V5218 | 42 BOLT (M8X1.25X35-MM) | 1 | |
| 6V5221 | 43 BOLT (M8X1.25X80-MM) | 1 | |
| 6V5230 | 44 BOLT (M10X1.5X60-MM) | 2 | |
| 6V5839 | 45 WASHER (11X21X2.5-MM THK) | 10 | |
| 6V5842 | 46 BOLT (M10X1.5X40-MM) | 2 | |
| 6V5843 | 47 BOLT (M10X1.5X45-MM) | 2 | |
| 6V8212 | 48 BOLT (M10X1.5X16-MM) | 1 | |
| 7C9560 | 50 SPACER (10.5X25X51-MM THK) | 1 | |
| 7K4129 | 51 UNION-FLARED | 1 | |
| 7V6571 | 52 GROMMET | 6 | |
| 8T0640 | 53 BOLT (M6X1X30-MM) | 1 | |
| 8T1889 | 54 CLIP (SLOT) | 6 | |
| 8T1890 | 55 CLIP (TAB) | 6 | |
| 8T4121 | 56 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T7934 | 58 WASHER-HARD (11X21X5-MM THK) | 1 | |
| 9M1974 | 59 WASHER-HARD (8.8X16X2-MM THK) | 1 |
