System And Components
267-1413 LINES GP-FUEL FILTERS/N LGK1-2280
Group No: 267-1413 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P0436 | 1 GASKET (FUEL PRIMING PUMP) | 1 | |
| 3S2093 | 2 STRAP-CABLE | 1 | |
| 4W9576 | 3 HOSE AS | 1 | |
| 4W9783 | 4 HOSE AS | 1 | |
| 6V0852 | 5 CAP-DUST | 1 | |
| 6Y1352 | 6 SPACER (10.5X20X27-MM THK) | 1 | |
| 7C8246 | 7 SPACER (10.5X20X24-MM THK) | 1 | |
| 9C5344 | 8 SPACER (10.5X20X18-MM THK) | 1 | |
| 9J6189 | 9 CLIP | 1 | |
| 1057704 | 10 TEE | 1 | |
| 1236948 | 11 PLUG | 1 | |
| 1375541 | 12 PUMP GP-FUEL PRIMING | 1 | |
| 1396873 | 13 VALVE GP-FUEL BYPASS (FILTER) | 1 | |
| 1608124 | 14 PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 1759079 | 15 ROD-LINK | 1 | |
| 1954778 | 16 SPACER | 1 | |
| 1978391 | 17 SENSOR GP-TEMPERATURE (FUEL) | 1 | |
| 2157350 | 18 BRACKET | 1 | |
| 2330077 | 19 HOSE AS | 1 | |
| 2336742 | 20 VALVE GP-CHECK (FUEL) | 1 | |
| 2379314 | 21 BASE AS | 1 | |
| 9S4167 | STUD-HOLLOW (1-14X1.47-IN) | 1 | |
| 2392396 | 22 SENSOR GP-PRESSURE (FUEL) | 1 | |
| 2408721 | 23 HARNESS AS-ENGINE (FUEL FILTER) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 1028806 | KIT-RECEPTACLE (8-PIN) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 2 | |
| 2466645 | 24 TUBE AS | 1 | |
| 0054362 | 25 ELBOW | 1 | |
| 0307942 | 26 ELBOW | 1 | |
| 0307947 | 27 ADAPTER-ELBOW | 3 | |
| 0308188 | 28 CONNECTOR | 3 | |
| 0336028 | 29 SEAL-O-RING | 2 | |
| 1325789 | 30 CLIP (LADDER) | 1 | |
| 2067337 | 31 TUBE AS | 1 | |
| 3E4352 | 32 WASHER-HARD (8.8X20.5X2.5-MM THK) | 1 | |
| 4D7735 | 33 CLIP | 1 | |
| 5P0537 | 34 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 6V1819 | 35 BOLT (M10X1.5X100-MM) | 1 | |
| 6V3922 | 36 SEAL-O-RING | 1 | |
| 6V3965 | 37 FITTING (QUICK DISCONNECT) | 1 | |
| 6V4589 | 38 SEAL-O-RING | 1 | |
| 6V5049 | 39 SEAL-O-RING | 6 | |
| 6V5215 | 40 BOLT (M8X1.25X16-MM) | 1 | |
| 6V5218 | 41 BOLT (M8X1.25X35-MM) | 1 | |
| 6V5839 | 42 WASHER (11X21X2.5-MM THK) | 7 | |
| 6V5842 | 43 BOLT (M10X1.5X40-MM) | 3 | |
| 6V5843 | 44 BOLT (M10X1.5X45-MM) | 3 | |
| 7J9108 | 45 SEAL-O-RING | 1 | |
| 7K4129 | 46 UNION-FLARED | 1 | |
| 8L2786 | 47 SEAL-O-RING | 5 | |
| 8M2773 | 48 CLIP (LOOP) | 1 | |
| 8T0640 | 49 BOLT (M6X1X30-MM) | 1 | |
| 9M1974 | 50 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 9S4185 | 51 PLUG (3/4-16-THD) | 2 | |
| 9X0261 | 52 ADAPTER | 1 |
