System And Components
267-1413 LINES GP-FUEL FILTERS/N A5K1-UP
Group No: 267-1413
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P0436 | 1 GASKET (FUEL PRIMING PUMP) | 1 | |
| 3S2093 | 2 STRAP-CABLE | 1 | |
| 6V0852 | 3 CAP-DUST | 1 | |
| 6Y1352 | 4 SPACER (10.5X20X27-MM THK) | 1 | |
| 7C8246 | 5 SPACER (10.5X20X24-MM THK) | 1 | |
| 9J6189 | 6 CLIP | 1 | |
| 1057704 | 7 TEE | 1 | |
| 1236948 | 8 PLUG | 1 | |
| 1396873 | 9 VALVE GP-FUEL BYPASS (FILTER) | 1 | |
| 1759079 | 10 ROD-LINK | 1 | |
| 2157350 | 11 BRACKET | 1 | |
| 2336742 | 12 VALVE GP-CHECK (FUEL) | 1 | |
| 2345013 | 13 SENSOR GP-TEMPERATURE (FUEL) | 1 | |
| 2379314 | 14 BASE AS | 1 | |
| 9S4167 | STUD-HOLLOW (1-14X1.47-IN) | 1 | |
| 2392396 | 15 SENSOR GP-PRESSURE (FUEL) | 1 | |
| 2490164 | 16 HOSE AS | 1 | |
| 2726666 | 17 TUBE AS | 1 | |
| 2726667 | 18 TUBE AS | 1 | |
| 2726668 | 19 HOSE AS | 1 | |
| 2788844 | 20 PLUG AS-CONNECTOR | 1 | |
| 8T8737 | PLUG-SEAL | 2 | |
| 2304011 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 2647029 | SEAL-CONNECTOR | 1 | |
| 0054362 | 21 ELBOW | 2 | |
| 0307942 | 22 ELBOW | 1 | |
| 1917805 | 23 ELBOW AS | 1 | |
| 0307947 | ADAPTER-ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 0308188 | 24 CONNECTOR | 1 | |
| 0336028 | 25 SEAL-O-RING | 2 | |
| 1325789 | 26 CLIP (LADDER) | 1 | |
| 1375541 | 27 PUMP GP-FUEL PRIMING | 1 | |
| 2067337 | 28 TUBE AS | 1 | |
| 2763099 | 29 HARNESS AS-ENGINE (FUEL FILTER) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 1028806 | KIT-RECEPTACLE (8-PIN) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 12 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 12 | |
| 1809340 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 2 | |
| 2304011 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 2647029 | SEAL-CONNECTOR | 1 | |
| 2304012 | RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 8T8737 | PLUG-SEAL | 1 | |
| 2R6806 | 30 CONNECTOR | 1 | |
| 3E4352 | 31 WASHER-HARD (8.8X20.5X2.5-MM THK) | 1 | |
| 3368613 | 32 CLIP (LOOP) | 1 | |
| 5P0537 | 33 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 2385081 | 34 SEAL-O-RING | 1 | |
| 6V3965 | 35 FITTING (QUICK DISCONNECT) | 1 | |
| 6V4248 | 36 BOLT (M10X1.5X25-MM) | 1 | |
| 6V4589 | 37 SEAL-O-RING | 1 | |
| 6V5049 | 38 SEAL-O-RING | 4 | |
| 6V5217 | 39 BOLT (M8X1.25X20-MM) | 1 | |
| 6V5218 | 40 BOLT (M8X1.25X35-MM) | 1 | |
| 6V5839 | 41 WASHER (11X21X2.5-MM THK) | 7 | |
| 6V5842 | 42 BOLT (M10X1.5X40-MM) | 3 | |
| 6V5843 | 43 BOLT (M10X1.5X45-MM) | 3 | |
| 7B9919 | 44 CLIP | 1 | |
| 7D9984 | 45 ELBOW | 1 | |
| 7H7055 | 46 CLIP | 1 | |
| 2287091 | 47 SEAL-O-RING | 1 | |
| 7K4129 | 48 UNION-FLARED | 1 | |
| 8L2786 | 49 SEAL-O-RING | 5 | |
| 8T0640 | 50 BOLT (M6X1X30-MM) | 1 | |
| 9M1974 | 51 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 9S4185 | 52 PLUG (3/4-16-THD) | 2 | |
| 9X0261 | 53 ADAPTER | 1 |
