System And Components
7Y-9021 FRAME GP-UPPERS/N 8HK1-99999; 9FL1-401
Group No: 7Y-9021
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1123945 | 1 FRAME AS | 1 | |
| 4I4996 | 2 PIN AS | 2 | |
| 1066859 | 3 PIN AS | 1 | |
| 7X2573 | 4 BOLT (M24X3X40-MM) | 3 | |
| 4I3183 | 5 WASHER (26X70X8-MM THK) | 3 | |
| 8T4167 | 6 WASHER-HARD (26X44X4-MM THK) | 3 | |
| 0930076 | 7 SHIM (1-MM THK) | 2 | |
| 0997468 | 8 SHIM (1.5-MM THK) | 1 | |
| 0930108 | 9 SHIM (2-MM THK) | 1 | |
| 4I1129 | 10 SPACER (113X150X14-MM THK) | 2 | |
| 4I0575 | 11 SHIM (1-MM THK) | 4 | |
| 4I0576 | 12 SHIM (1.6-MM THK) | 2 | |
| 4I0577 | 13 SHIM (2-MM THK) | 2 | |
| 1K8850 | 14 SPRING | 1 | |
| 5V3854 | 15 BUMPER | 1 | |
| 8T5413 | 16 STUD-WELD (M10X1.5X25-MM) | 2 | |
| 8T4121 | 17 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4133 | 18 NUT (M10X1.5-THD) | 2 | |
| 0873765 | 19 DOOR AS | 1 | |
| 4K8501 | CLIP | 2 | |
| 9V3659 | HINGE | 1 | |
| 7Y9267 | 20 SPACER (133X190X14-MM THK) | 1 |
