1G-9878 BATTERY & WIRING GPS/N 5RN1-95

Group No: 1G-9878

Part Number	Part Name	Qty
3T5760	1 BATTERY GP (12-VOLT, 750-CCA)	2
9V6943	2 CABLE AS	1
5P0746	CABLE (0-GA, BLACK)(20CM)
7X1169	2A TERMINAL AS-BATTERY (NEGATIVE)	1
7N5274	COVER AS-TERMINAL (BLACK)	1
1M6119	2B BOLT (5/16-18X1.375-IN)	2
1M6120	NUT (5/16-18-THD)	2
8T9758	2C TERMINAL AS (POSITIVE)	1
8N1725	COVER AS-TERMINAL (RED)	1
8T4121	3 WASHER-HARD (11X21X2.5-MM THK)	8
8T4144	4 BOLT (M10X1.5X260-MM)	4
6V7744	LOCKNUT (M10X1.5-THD)	4
9R5685	5 HOLDER AS	2
9X0941	6 LOCKNUT (1/2-13-THD)	1
1080405	7 CABLE AS	1
5P0761	CABLE (00-GA, RED)(58CM)
1S7252	TERMINAL-CABLE (00-GA, 3/8-IN SCREW)	1
8N0869	COVER-TERMINAL (RED)	1
3S6049	7A TERMINAL AS-BATTERY (POSITIVE)	1
1M6119	BOLT (5/16-18X1.375-IN)	1
1M6120	NUT (5/16-18-THD)	1
8N1725	COVER AS-TERMINAL (RED)	1
8T4896	8 WASHER-HARD (10.2X18.5X2.5-MM THK)	1
6D3479	9 CLIP (LOOP)	4
8T4137	BOLT (M10X1.5X20-MM)	4
7V6571	10 GROMMET	2
1060800	11 CONNECTOR GP (REMOTE JUMP START, POSITIVE)	1
6V8801	12 NUT (3/8-16-THD)	1
1060539	13 CABLE AS	1
5P0761	CABLE (00-GA, RED)(170CM)
1S7252	TERMINAL-CABLE (00-GA, 3/8-IN SCREW)	2
4S1936	14 CLIP	2
8T4179	15 BOLT (M12X1.75X20-MM)	2
8T4223	16 WASHER-HARD (13.5X25.5X3-MM THK)	3
3P2181	17 CABLE AS	1
5P0747	CABLE (00-GA, BLACK)(61CM)
1S7252	TERMINAL-CABLE (00-GA, 3/8-IN SCREW)	1
0375197	BOOT	1
3S6050	17A TERMINAL AS-BATTERY (NEGATIVE)	1
1M6119	BOLT (5/16-18X1.375-IN)	1
1M6120	NUT (5/16-18-THD)	1
7N5274	COVER AS-TERMINAL (BLACK)	1
4D1326	18 LOCKWASHER	1
7N0718	19 SWITCH GP-DISCONNECT (BATTERY)	1
8H8648	20 PLATE-INSTRUCTION (DISCONNECT SWITCH)	1
5Y1423	21 CABLE AS	2
5P0747	CABLE (00-GA, BLACK)(33CM)
1S7252	TERMINAL-CABLE (00-GA, 3/8-IN SCREW)	1
1S7251	TERMINAL-CABLE (00-GA, 1/2-IN SCREW)	1
8N0869	22 COVER-TERMINAL (RED)	1
8T2561	23 WASHER-HARD (10.5X28.5X5-MM THK)	4
4M7146	24 STRAP AS-GROUND	1
5M3062	25 BOLT (3/8-16X0.75-IN)	1
6D3479	26 CLIP (LOOP)	1
