System And Components
1G-9878 BATTERY & WIRING GPS/N 5RN96-UP
Group No: 1G-9878
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3T5760 | 1 BATTERY GP (12-VOLT, 750-CCA) | 2 | |
| 9V6943 | 2 CABLE AS | 1 | |
| 5P0746 | CABLE (0-GA, BLACK)(20CM) | ||
| 7X1169 | 2A TERMINAL AS-BATTERY (NEGATIVE) | 1 | |
| 7N5274 | COVER AS-TERMINAL (BLACK) | 1 | |
| 1M6119 | 2B BOLT (5/16-18X1.375-IN) | 2 | |
| 1M6120 | NUT (5/16-18-THD) | 2 | |
| 8T9758 | 2C TERMINAL AS (POSITIVE) | 1 | |
| 8N1725 | COVER AS-TERMINAL (RED) | 1 | |
| 6R4329 | 3 CABLE AS | 1 | |
| 5P0747 | CABLE (00-GA, BLACK)(66CM) | ||
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 1 | |
| 1S7252 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 1 | |
| 8T4121 | 4 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4144 | 5 BOLT (M10X1.5X260-MM) | 4 | |
| 6V7744 | LOCKNUT (M10X1.5-THD) | 4 | |
| 1K6872 | 6 LOCKNUT (1/2-13-THD) | 1 | |
| 1080405 | 7 CABLE AS | 1 | |
| 5P0761 | CABLE (00-GA, RED)(58CM) | ||
| 1S7252 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 1 | |
| 8N0869 | COVER-TERMINAL (RED) | 1 | |
| 3S6049 | 7A TERMINAL AS-BATTERY (POSITIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 8N1725 | COVER AS-TERMINAL (RED) | 1 | |
| 9R5685 | 8 HOLDER AS | 2 | |
| 6D3479 | 9 CLIP (LOOP) | 4 | |
| 8T4137 | BOLT (M10X1.5X20-MM) | 4 | |
| 7V6571 | 10 GROMMET | 2 | |
| 1060800 | 11 CONNECTOR GP (REMOTE JUMP START, POSITIVE) | 1 | |
| 6V8801 | 12 NUT (3/8-16-THD) | 1 | |
| 1060539 | 13 CABLE AS | 1 | |
| 5P0761 | CABLE (00-GA, RED)(170CM) | ||
| 1S7252 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 2 | |
| 4S1936 | 14 CLIP | 2 | |
| 8T4179 | 15 BOLT (M12X1.75X20-MM) | 1 | |
| 8T4223 | 16 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 3P2181 | 17 CABLE AS | 1 | |
| 5P0747 | CABLE (00-GA, BLACK)(61CM) | ||
| 1S7252 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 1 | |
| 0375197 | BOOT | 1 | |
| 3S6050 | 17A TERMINAL AS-BATTERY (NEGATIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 7N5274 | COVER AS-TERMINAL (BLACK) | 1 | |
| 8T4896 | 18 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 7N0718 | 19 SWITCH GP-DISCONNECT (BATTERY) | 1 | |
| 8H8648 | 20 PLATE-INSTRUCTION (DISCONNECT SWITCH) | 1 | |
| 5Y1423 | 21 CABLE AS | 1 | |
| 5P0747 | CABLE (00-GA, BLACK)(33CM) | ||
| 1S7252 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 1 | |
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 1 | |
| 8N0869 | 22 COVER-TERMINAL (RED) | 1 | |
| 8T2561 | 23 WASHER-HARD (10.5X28.5X5-MM THK) | 4 | |
| 4M7146 | 24 STRAP AS-GROUND | 1 | |
| 5M3062 | 25 BOLT (3/8-16X0.75-IN) | 1 | |
| 6D3479 | 26 CLIP (LOOP) | 1 | |
| 4D1326 | 27 LOCKWASHER | 1 |
