139-0072 WIRING GP-PLATFORMS/N 3TM628-UP

Group No: 139-0072
Part NumberPart NameQty
3E52391 RELAY AS (24-VOLT)(ENGINE OIL PRESSURE)1
7T09692 HORN AS (24-VOLT, LOW TONE)2
8C7581SCREW-MACHINE (M4X0.7X8-MM)2
9B7233LOCKWASHER2
0966166WASHER-HARD (4.5X9X1-MM THK)2
3E00753 SWITCH GP-MAGNETIC (24-VOLT)(STARTER RELAY)1
16701384 SWITCH GP-MAGNETIC (24-VOLT)(MAIN RELAY)1
4M71465 STRAP AS-GROUND1
9S01746 CIRCUIT BREAKER AS (60-AMPERE)1
1H3244LOCKWASHER2
6V8187NUT (1/4-28-THD)2
8T4205WASHER-HARD (7.2X14.5X2-MM THK)2
14036917 CONSOLE GP-INSTRUMENT1
8T41898 BOLT (M8X1.25X20-MM)5
5P41169 WASHER-HARD (8.8X20.5X2-MM THK)5
8T419110 BOLT (M10X1.5X16-MM)3
8T412111 WASHER-HARD (11X21X2.5-MM THK)6
8T419512 BOLT (M10X1.5X30-MM)3
7K118113 STRAP-CABLE15
9X825614 WASHER (6.6X12X2-MM THK)4
112664615 LOCKNUT (M6X1-THD)14
8T413816 BOLT (M6X1X20-MM)18
134482317 HARNESS AS-PLATFORM1
138900318 CONSOLE GP-OPERATOR1
2S955619 SCREW-MACHINE (10-32X0.875-IN)2
4B427420 WASHER (5.5X13X1.2-MM THK)2
3B450221 LOCKWASHER2
9G915422 CLIP2
7C435423 CLIP4
8T413324 NUT (M10X1.5-THD)3
5M306225 BOLT (3/8-16X0.75-IN)2
8T489626 WASHER-HARD (10.2X18.5X2.5-MM THK)2
8T879927 BOOT (RED)6
3E523928 RELAY AS (24-VOLT)(COOLANT TEMP)1
3E523929 RELAY AS (24-VOLT)(WARNING LIGHT)1
3E523930 RELAY AS (24-VOLT)(HYD OIL TEMP)1
3E523931 RELAY AS (24-VOLT)(FUNCTIONAL LIGHT)1
3E523932 RELAY AS (24-VOLT)(BRAKE #1)1
3E523933 RELAY AS (24-VOLT)(BRAKE #2)1
3E523934 RELAY AS (24-VOLT)(NEUTRAL START #1)1
3E523935 RELAY AS (24-VOLT)(NEUTRAL START #2)1
3E523936 RELAY AS (24-VOLT)(LOW CHARGE)1
