141-7801 WIRING GP-PLATFORMS/N 2JM508-UP; 3TM614-UP

Group No: 141-7801

Part Number	Part Name	Qty
3E5239	1 RELAY AS (24-VOLT)(FUNCTIONAL LIGHT)	1
7T0969	2 HORN AS (24-VOLT, LOW TONE)	2
8C7581	SCREW-MACHINE (M4X0.7X8-MM)	2
9B7233	LOCKWASHER	2
3E0075	3 SWITCH GP-MAGNETIC (24-VOLT)(STARTER RELAY)	1
1670138	4 SWITCH GP-MAGNETIC (24-VOLT)(MAIN RELAY)	1
4M7146	5 STRAP AS-GROUND	1
9S0174	6 CIRCUIT BREAKER AS (60-AMPERE)	1
1H3244	LOCKWASHER	2
6V8365	SCREW-MACHINE (1/4-28X0.5-IN)	2
1403691	7 CONSOLE GP-INSTRUMENT	1
8T4189	8 BOLT (M8X1.25X20-MM)	5
5P4116	9 WASHER-HARD (8.8X20.5X2-MM THK)	5
8T4191	10 BOLT (M10X1.5X16-MM)	3
8T4121	11 WASHER-HARD (11X21X2.5-MM THK)	6
8T4195	12 BOLT (M10X1.5X30-MM)	3
7K1181	13 STRAP-CABLE	15
9X8256	14 WASHER (6.6X12X2-MM THK)	14
1126646	15 LOCKNUT (M6X1-THD)	14
8T4138	16 BOLT (M6X1X20-MM)	18
1170842	17 HARNESS AS-PLATFORM	1
1091035	18 CONSOLE GP-OPERATOR	1
2S9556	19 SCREW-MACHINE (10-32X0.875-IN)	2
4B4274	20 WASHER (5.5X13X1.2-MM THK)	2
3B4502	21 LOCKWASHER	2
9G9154	22 CLIP	2
8T4896	23 WASHER-HARD (10.2X18.5X2.5-MM THK)	2
8T8799	24 BOOT (RED)	6
7C4354	25 CLIP	4
8T4133	26 NUT (M10X1.5-THD)	3
5M3062	27 BOLT (3/8-16X0.75-IN)	2
3E5239	28 RELAY AS (24-VOLT)(HYD OIL TEMP)	1
3E5239	29 RELAY AS (24-VOLT)(WARN LIGHT)	1
3E5239	30 RELAY AS (24-VOLT)(COOL TEMP)	1
3E5239	31 RELAY AS (24-VOLT)(ENG OIL PRESSURE)	1
3E5239	32 RELAY AS (24-VOLT)(BRAKE 1)	1
3E5239	33 RELAY AS (24-VOLT)(BRAKE 2)	1
3E5239	34 RELAY AS (24-VOLT)(NEUTRAL START 1)	1
3E5239	35 RELAY AS (24-VOLT)(NEUTRAL START 2)	1
3E5239	36 RELAY AS (24-VOLT)(LOW CHARGE)	1
8T4205	37 WASHER-HARD (7.2X14.5X2-MM THK)	4
