System And Components
8N-7268 FILTER GP-ENGINE OIL -LHS/N 78Z1144-4866
Group No: 8N-7268
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6N3732 | 1 ELBOW | 2 | |
| 0L1143 | 2 BOLT (3/8-16X2.5-IN) | 4 | |
| 1L6939 | 3 ELBOW | 4 | |
| 5P6923 | 4 ADAPTER | 2 | |
| 8M9024 | 5 WASHER-HARD (10.2X22.5X5-MM THK) | 11 | |
| 0S1594 | 6 BOLT (3/8-16X1-IN) | 10 | |
| 5M2894 | 7 WASHER-HARD (10.2X18.5X2.5-MM THK) | 62 | |
| 6N3169 | 8 HOSE AS | 1 | |
| 2P4305 | 9 GASKET | 5 | |
| 2P4303 | 10 BASE AS-OIL FILTER | 1 | |
| 2P4304 | STUD-HOLLOW | 1 | |
| 0S1571 | 11 BOLT (3/8-16X1.75-IN) | 9 | |
| 2P4301 | 12 BASE AS-OIL FILTER | 2 | |
| 2P4304 | STUD-HOLLOW | 1 | |
| 0S1588 | 13 BOLT (3/8-16X1.25-IN) | 6 | |
| 2P3761 | 14 COVER | 3 | |
| 2P3760 | 15 GASKET | 3 | |
| 2M1538 | 16 STUD-TAPERLOCK (3/8-16X1.6-IN) | 8 | |
| 6N7420 | 17 COVER AS | 1 | |
| 3N4411 | 18 HOSE AS | 1 | |
| 0S1591 | 19 BOLT (3/8-16X1.5-IN) | 7 | |
| 6N4102 | 20 BRACKET | 1 | |
| 8F8513 | 21 CLIP (LOOP) | 2 | |
| 9F2940 | 22 GROMMET | 2 | |
| 1L6561 | 23 PLUG | 1 | |
| 2W3681 | 24 INDICATOR AS (ENGINE OIL PRESSURE) | 2 | |
| 7W2731 | 25 RETAINER | 2 | |
| 6V3507 | 26 SEAL-RECTANGULAR | 2 | |
| 4N7082 | 27 SHIELD-OIL FILTER | 3 | |
| 8N8292 | 29 TUBE AS | 1 | |
| 0L1351 | 30 BOLT (3/8-16X0.875-IN) | 6 | |
| 6N4202 | 31 BRACKET | 1 | |
| 0S1590 | 32 BOLT (3/8-16X2-IN) | 2 | |
| 1R1808 | 33 FILTER-ENGINE OIL (ADVANCED EFFICIENCY) | 3 | |
| 1090078 | 34 SEAL-O-RING | 6 | |
| 4N0933 | 35 GASKET | 3 | |
| 2N1287 | 36 ELBOW-FLARED | 2 | |
| 8N6788 | 37 BRACKET | 1 | |
| 2N5848 | 38 BASE AS | 1 | |
| 9F6580 | 39 BOLT (1/4-20X1.125-IN) | 3 | |
| 5P0537 | 40 WASHER-HARD (7.2X14.5X2-MM THK) | 6 | |
| 2N0179 | 41 COVER-PANEL | 1 | |
| 8B4884 | 42 ELBOW | 2 | |
| 5S7348 | 43 SCREW-MACHINE (6-32X0.375-IN) | 2 | |
| 4B5324 | 44 WASHER (3.9X9.6X1.2-MM THK) | 4 | |
| 4B2041 | 45 NUT (6-32-THD) | 2 | |
| 2N0178 | 46 PANEL | 1 | |
| 2B0941 | 47 SPACER (10.5X19X19-MM THK) | 4 | |
| 5H5138 | 48 CLIP | 2 | |
| 4N1199 | 49 CLIP | 1 | |
| 8M5260 | 50 SEAL-O-RING | 1 | |
| 6N4208 | 51 ADAPTER | 1 | |
| 1A2029 | 52 BOLT (3/8-16X1.125-IN) | 1 | |
| 6N1260 | 53 PLATE | 1 | |
| 5B2638 | 54 BOLT (3/8-16X5.25-IN) | 4 | |
| 6N1259 | 55 POINTER | 1 | |
| 1B8704 | 56 KEY-WOODRUFF | 2 | |
| 4H9756 | 57 LEVER-RELEASE CONTROL | 1 | |
| 7N0914 | 58 DETENT AS | 1 | |
| 6N4205 | PLATE | 1 | |
| 6N4204 | PIN | 2 | |
| 6J8356 | SPRING | 2 | |
| 7N0913 | RING | 1 | |
| 8F8833 | PIN | 1 | |
| 8H1607 | 59 SEAL-O-RING | 1 | |
| 7N0912 | 60 VALVE GP-FLUID CONTROL (ENGINE OIL) | 1 | |
| 7N0911 | VALVE AS (ENGINE OIL FILTER) | 1 | |
| 3F9190 | PIN | 1 | |
| 6N1258 | 61 HOUSING | 1 | |
| 6N0824 | 62 GASKET | 1 | |
| 7F9090 | 63 SCREW-DRIVE (NO 8X3/8-IN) | 6 | |
| 4N8150 | 64 SPRING | 3 | |
| 9M0853 | 65 PLUNGER-VALVE | 3 | |
| 2W8438 | 66 TUBE | 1 | |
| 6N4085 | 67 TUBE AS | 1 | |
| 0L2070 | 68 BOLT (3/8-16X2.25-IN) | 3 | |
| 1090076 | 69 SEAL-O-RING | 3 | |
| 6N4722 | 70 BODY | 1 | |
| 2P2772 | 71 COVER | 1 | |
| 6N0452 | 72 ELBOW-COOLER OUTLET | 1 | |
| 6N4109 | 73 CLIP | 1 | |
| 6N0822 | 74 ELBOW | 1 | |
| 6N7421 | 75 COVER AS | 1 | |
| 0T0102 | 76 BOLT (3/8-16X0.625-IN) | 2 | |
| 6N4061 | 77 TUBE | 1 | |
| 4B5271 | 78 WASHER (25.5X11.2X2-MM THK) | 2 | |
| 8N8289 | 79 TUBE AS | 1 | |
| 8S9191 | 80 BOLT (3/8-16X4-IN) | 2 | |
| 9B3429 | 81 LUG | 1 | |
| 1C2251 | 82 BOLT (3/8-16X1.87-IN) | 2 | |
| 9S8750 | 83 NUT-FULL (1/4-20-THD) | 3 | |
| 8T6764 | 84 PLUG-PIPE (1/8-27-THD) | 1 | |
| 9S8752 | 85 NUT-FULL (3/8-16-THD) | 30 | |
| 6D3479 | 86 CLIP (LOOP) | 1 | |
| 1L6561 | 87 PLUG | 1 | |
| 7X7730 | 88 PLUG-PIPE | 1 |
