9Y-1425 GENERATOR GPS/N 9FF2520-UP

Group No: 9Y-1425

Part Number	Part Name	Qty
4P3412	1 STATOR AS	1
2905567	2 HEAT SINK AS	1
1181324	3 BRACKET-BEARING	1
4P3153	4 SPACER (20.6X77X27.8-MM THK)	1
1A9579	5 BOLT (5/16-18X1.5-IN)	4
4P3152	6 ROTOR-EXCITER	1
9Y5816	8 STATOR-EXCITER	1
3H5932	9 BOLT (5/16-18X4.5-IN)	4
9M1974	10 WASHER-HARD (8.8X16X2-MM THK)	8
7E6573	11 COVER-DUST	1
4P4006	12 DEFLECTOR	1
6I0088	13 COVER AS-EXCITER	1
1B2714	14 BOLT (1/4-20X2.5-IN)	2
5P0537	15 WASHER-HARD (7.2X14.5X2-MM THK)	9
1112413	16 FAN-GENERATOR	1
1122563	17 SCREEN AS	2
1012993	20 COVER-DRIP	1
6I2737	21 RETAINER-BEARING	2
4P3149	22 PANEL-REAR	1
1N7219	28 CHANNEL-RUBBER	1
7E6578	29 PANEL	2
4P3150	31 COVER AS	1
5N3167	SEAL-RING	2
5N3176	PLUG-BUTTON	2
6D7128	SEAL-O-RING	4
8P7065	PLUG-BUTTON	2
8T9587	SEAL-O-RING	2
0302284	PLUG-BUTTON	4
7E6575	32 PANEL AS	1
4F8711	PLUG-BUTTON	2
5N3174	PLUG-BUTTON	8
5N3175	PLUG-BUTTON	1
6K9593	PLUG-BUTTON	1
0S1615	33 BOLT (1/4-20X0.75-IN)	9
5M6214	34 PLUG (1/8-27 PTF)	2
7E6568	35 FRAME AS (RH)	1
7E6572	36 BRACKET (RH)	1
7E6571	37 BRACKET (LH)	1
7E6567	38 FRAME AS (LH)	1
9F7022	39 BOLT (1/4-20X1.5-IN)	2
4P3413	40 ROTOR AS	1
5L2087	41 SPACER (9.25X13.72X50.8-MM THK)	2
4W9449	42 FILM-INFORMATION (GENERATOR WIRING DIAGRAM)	1
4P4007	43 DEFLECTOR-LOWER	1
4P5639	45 KIT-SPACE HEATER (GENERATOR)	1
4P3845	46 TRANSFORMER GP-CURRENT	1
8B0544	47 SPACER (12.5X17.14X25.4-MM THK)	2
4W3901	KIT-ROTOR BALANCE WEIGHT (GENERATOR)	1
9Y5735	KIT-STATOR REWIND (GENERATOR)	1
7E7233	KIT-GENERATOR HARDWARE	1
