System And Components
4W-3821 LINES GP-ENGINE OILS/N TXC1-UP
Group No: 4W-3821
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W6137 | 1 TUBE AS | 1 | |
| 2P3760 | 2 GASKET | 1 | |
| 4N0826 | 3 ELBOW | 1 | |
| 4N0913 | 4 SCREEN-STRAINER (ENGINE OIL LINE) | 1 | |
| 4N0914 | 5 CLIP | 1 | |
| 4N0995 | 6 TUBE AS | 1 | |
| 4N1216 | 7 TUBE-COOLER BYPASS (ENGINE OIL) | 1 | |
| 4N6228 | 8 PIPE AS | 1 | |
| 4N6229 | 9 SUPPORT-BELL | 1 | |
| 4N7489 | 10 SCREEN-INLET | 1 | |
| 4N7497 | 11 TUBE AS | 1 | |
| 4N8150 | 12 SPRING | 1 | |
| 8N2104 | 13 BELL AS-SUCTION | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 2 | |
| 3929208 | 14 PLUNGER-VALVE (RELIEF) | 1 | |
| 2030147 | 15 TUBE AS | 1 | |
| 2235814 | 16 BODY-COOLER BYPASS (ENGINE OIL) | 1 | |
| 3218642 | 17 PLUG AS | 2 | |
| 9S8003 | PLUG (1/2-20-THD) | 1 | |
| 2147567 | SEAL-O-RING | 1 | |
| 0L1351 | 18 BOLT (3/8-16X0.875-IN) | 2 | |
| 0S1588 | 19 BOLT (3/8-16X1.25-IN) | 4 | |
| 0S1590 | 20 BOLT (3/8-16X2-IN) | 2 | |
| 0S1591 | 21 BOLT (3/8-16X1.5-IN) | 8 | |
| 0S1594 | 22 BOLT (3/8-16X1-IN) | 10 | |
| 1A2029 | 23 BOLT (3/8-16X1.125-IN) | 2 | |
| 2N3350 | 24 SEAL-O-RING | 2 | |
| 2P3761 | 25 COVER | 1 | |
| 3E6790 | 26 SEAL-O-RING | 1 | |
| 1135304 | 27 SEAL-O-RING | 2 | |
| 5M2894 | 28 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 5P5846 | 29 SEAL-O-RING | 1 | |
| 5P8068 | 30 SEAL-O-RING | 4 | |
| 8C5230 | 31 SEAL-O-RING | 2 | |
| 9X6458 | 32 WASHER-HARD (10.2X22.5X3-MM THK) | 2 |
