258-9764 WIRING GP-ENGINES/N C1J1-747

Group No: 258-9764

Part Number	Part Name	Qty
3S2093	1 STRAP-CABLE	43
4H1225	2 WASHER (11X22X6-MM THK)	2
7Y1924	3 SPACER (9X19X23-MM THK)	1
1085678	4 UNION	1
1170067	5 ELBOW	1
1309811	6 SENSOR GP-TEMPERATURE (INLET AIR)	1
1329770	7 SPACER AS	1
1W6448	DOWEL	2
1611703	8 SENSOR GP-PRESSURE (CRANKCASE)	1
1611705	9 SENSOR AS-PRESSURE (ENGINE OIL)	1
2042518	10 SENSOR GP-LIQUID LEVEL	1
2039609	11 HARNESS AS-ENGINE (PANEL INTERCONNECT)(JUMPER)	1
1028801	KIT-RECEPTACLE (12-PIN)	1
1155674	BOOT (UNIT INJECTOR)	2
1552255	KIT-CONNECTING PLUG (12-PIN)	1
1809340	SOCKET-CONNECTOR (14-GA TO 18-GA)	7
1945226	TERMINAL AS (16-GA)	1
1945227	TERMINAL AS (14-GA)	1
2116833	12 BRACKET AS	1
7C2644	CLIP	1
8C3334	RIVET-TUBULAR	2
2556451	13 HARNESS AS-CONTROL	1
1028802	KIT-RECEPTACLE (2-PIN)	4
1028803	KIT-RECEPTACLE (3-PIN)	4
6I4347	BOOT (4-PIN)	21
6I4348	BOOT (40-PIN)	2
1863736	SOCKET-CONNECTOR (16-GA TO 18-GA)	3
9X0141	PLUG AS-CONNECTOR (40-PIN)	1
3E4367	RING-RETAINING	1
3E8557	BOLT (M5X0.8X39.37-MM)	1
9X3490	SEAL-CONNECTOR (40-PIN)	2
9X6772	STRAP-CABLE	4
1155674	BOOT (UNIT INJECTOR)	2
1257874	TUBE-HEAT SHRINK (5.72-MM DIA)(90-CM)
1257875	TUBE-HEAT SHRINK (7.44-MM DIA)(100-CM)
1261774	COVER-CONNECTOR	2
1552255	KIT-CONNECTING PLUG (12-PIN)	2
1552260	KIT-CONNECTING PLUG (3-PIN)	9
1552270	KIT-CONNECTING PLUG (2-PIN)	10
1607690	PLUG AS-CONNECTOR (70-PIN)	2
1599322	SEAL-O-RING	1
1552260	KIT-CONNECTING PLUG (3-PIN)	1
1809340	SOCKET-CONNECTOR (14-GA TO 18-GA)	168
1945226	TERMINAL AS (16-GA)	1
1945227	TERMINAL AS (14-GA)	1
2556452	14 HARNESS AS-CONTROL	1
1028805	KIT-RECEPTACLE (6-PIN)	1
1028801	KIT-RECEPTACLE (12-PIN)	1
3S2093	STRAP-CABLE	1
5P6001	TUBE-HEAT SHRINK (4.75-MM DIA)(0.3-M)
6I4347	BOOT (4-PIN)	3
6I4348	BOOT (40-PIN)	2
8C6354	CAP-RECEPTACLE (ET CONNECTOR)	1
8T8736	RECEPTACLE-CONNECTOR (9-PIN)	1
9X6772	STRAP-CABLE	4
1030213	RECEPTACLE AS-CONNECTOR (70-PIN)	1
1155674	BOOT (UNIT INJECTOR)	3
1193662	TUBE-HEAT SHRINK (10.85-MM DIA)(33-CM)
1257874	TUBE-HEAT SHRINK (5.72-MM DIA)(105-CM)
1257875	TUBE-HEAT SHRINK (7.44-MM DIA)(105-CM)
1257876	TUBE-HEAT SHRINK (17.78-MM DIA)(25-CM)
1261774	COVER-CONNECTOR	2
1330967	PIN-CONNECTOR (16-GA TO 18-GA)	3
1330969	CONNECTOR-SOCKET (16-GA TO 18-GA)	2
1532707	CABLE-ELECTRICAL (2-CONDUCTOR, 18-GA)(325-CM)
1552255	KIT-CONNECTING PLUG (12-PIN)	1
1552270	KIT-CONNECTING PLUG (2-PIN)	2
1607689	PLUG AS-CONNECTOR (70-PIN)	2
1599322	SEAL-O-RING	1
1809340	SOCKET-CONNECTOR (14-GA TO 18-GA)	73
1945226	TERMINAL AS (16-GA)	1
1945227	TERMINAL AS (14-GA)	1
2080432	PLUG	1
2632732	15 WIRE AS	2
0S0509	16 BOLT (3/8-16X0.75-IN)	4
0S1588	17 BOLT (3/8-16X1.25-IN)	3
0S1591	18 BOLT (3/8-16X1.5-IN)	1
0S1594	19 BOLT (3/8-16X1-IN)	2
1013625	20 CLIP (LADDER)	4
1325789	21 CLIP (LADDER)	5
1918303	22 SENSOR GP-SPEED (LOW OUTPUT)(TIMING, CRANKSHAFT)	1
1A2029	23 BOLT (3/8-16X1.125-IN)	2
2016617	24 SENSOR GP-SPEED (TIMING, CAMSHAFT)	1
2183840	25 SENSOR GP-PRESSURE (3-PIN)(BOOST)	1
2H3755	26 BOLT (5/16-18X0.43-IN)	2
3P0647	27 SEAL-O-RING	2
3P1155	28 SEAL-O-RING	1
4B5324	29 WASHER (3.9X9.6X1.2-MM THK)	4
4L6454	30 BOLT (3/8-16X1-IN)	2
4P7581	31 CLIP (LADDER)	4
4P8134	32 CLIP (LADDER)	11
4S1962	33 CLIP (LOOP)	4
5M2894	34 WASHER-HARD (10.2X18.5X2.5-MM THK)	12
6V5048	35 SEAL-O-RING	5
6V5049	36 SEAL-O-RING	2
6V8189	37 NUT (5/16-18-THD)	1
6V8801	38 NUT (3/8-16-THD)	8
8L2786	39 SEAL-O-RING	4
8T4224	40 WASHER-HARD (8.8X16X2-MM THK)	1
8T4896	41 WASHER-HARD (10.2X18.5X2.5-MM THK)	10
9M1974	42 WASHER-HARD (8.8X16X2-MM THK)	2
9X0261	43 ADAPTER	1
9X6258	44 SCREW-MACHINE (6-32X0.5-IN)	4
1309811	45 SENSOR GP-TEMPERATURE (FUEL OUTLET)	1
1309811	46 SENSOR GP-TEMPERATURE (FUEL)	1
1309811	47 SENSOR GP-TEMPERATURE (COOLANT)	1
1611705	48 SENSOR AS-PRESSURE (FUEL)	1
