System And Components
283-6372 FILTER GP-FUELAN ATTACHMENT
Group No: 283-6372
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1R0755 | 1 FILTER-FUEL (ADVANCED EFFICIENCY) | 2 | |
| 1W7559 | 2 BASE AS-FUEL FILTER | 2 | |
| 8N3653 | 2A STUD-TAPERLOCK | 1 | |
| 6N1127 | 2B SHIELD | 1 | |
| 7F9090 | 2C SCREW-DRIVE (NO 8X3/8-IN) | 2 | |
| 6T3642 | 3 CIRCUIT BREAKER AS (10-AMPERE) | 1 | |
| 6V8376 | SCREW-MACHINE (8-32X0.25-IN) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 3012980 | 4 SWITCH AS-TOGGLE (ROTOR TURNING)(PRIMING PUMP) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 3E3371 | WEDGE-RECEPTACLE LOCK (3-PIN) | 1 | |
| 6T3631 | NUT-HEX (15/32-32-THD) | 1 | |
| 6T3632 | LOCKWASHER | 1 | |
| 3E3390 | PIN-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 2054757 | 5 SHIELD AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 2455956 | 6 ADAPTER-FUEL | 1 | |
| 2836373 | 7 SUPPORT AS | 1 | |
| 8D1059 | 7A BLOCK | 1 | |
| 0S0509 | 8 BOLT (3/8-16X0.75-IN) | 3 | |
| 1488411 | 9 PLUG AS | 3 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 2495492 | 10 GUARD-SWITCH (TOGGLE) | 1 | |
| 1A2029 | 11 BOLT (3/8-16X1.125-IN) | 5 | |
| 2A4639 | 12 BOLT (3/8-16X1.625-IN) | 4 | |
| 2K8198 | 13 SEAL-O-RING | 4 | |
| 3B1915 | 14 BOLT (3/8-16X1.375-IN) | 9 | |
| 4B4863 | 15 WASHER (4.7X11X1.2-MM THK) | 2 | |
| 5M2894 | 16 WASHER-HARD (10.2X18.5X2.5-MM THK) | 24 | |
| 6V7345 | 17 SCREW-MACHINE (8-32X0.875-IN) | 2 | |
| 9S8752 | 18 NUT-FULL (3/8-16-THD) | 4 | |
| 9X6458 | 19 WASHER-HARD (10.2X22.5X3-MM THK) | 1 |
