System And Components
4W-6144 CYLINDER BLOCK GPS/N 99U4605-4653
Group No: 4W-6144
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7M7410 | 1 PLUG-PIPE (9.53MM PIPE THD) | 6 | |
| 9S4190 | 2 PLUG-O-RING (7/8-14-THD) | 4 | |
| 2M9780 | SEAL-O-RING | 4 | |
| 9F2247 | 3 PLUG-PIPE (1/8-27-THD)(3.18MM PIPE THD) | 9 | |
| 4N1650 | 4 DOWEL | 4 | |
| 6N9133 | 5 GASKET-PLATE | 2 | |
| 3S6605 | 6 PLUG-CUP (8.05MM O.D.) | 2 | |
| 4N4178 | 7 PLATE-BLOCK | 2 | |
| 3B0645 | 8 PLUG-CUP (32.08-MM OD) | 1 | |
| 4N9916 | 9 BOLT | 8 | |
| 4N9881 | 10 JET AS-PISTON COOLING | 8 | |
| 4N0693 | 11 PLUG-TAPERLOCK (1-1/2-12-THD)(38.10MM O.D.) | 3 | |
| 7H3171 | 12 PLUG-PIPE | 4 | |
| 8M8283 | 13 SEAL-O-RING | 2 | |
| 1W5081 | 14 CYLINDER BLOCK AS | 1 | |
| 4N0683 | 15 DOWEL | 4 | |
| 4W6061 | 16 SLEEVE | 1 | |
| 4W4588 | SLEEVE-LIFTER BORE | 1 | |
| 2W3815 | INSERT-LINER SEAT (1.605-MM THK) | 1 | |
| 6I4363 | INSERT-LINER SEAT (1.555-MM THK) | ||
| 6I4364 | INSERT-LINER SEAT (1.655-MM THK) | ||
| 5N0093 | INSERT-LINER SEAT (2.71-MM THK) | 1 | |
| 6I4365 | INSERT-LINER SEAT (2.66-MM THK) | ||
| 6I4366 | INSERT-LINER SEAT (2.76-MM THK) |
