System And Components
1W-5082 CYLINDER BLOCK GPS/N 67U11135-11136
Group No: 1W-5082
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7W7496 | 1 JET AS-PISTON COOLING | 8 | |
| 4N1650 | 2 DOWEL | 4 | |
| 7H3171 | 3 PLUG-PIPE | 4 | |
| 1W5081 | 4 CYLINDER BLOCK AS | 1 | |
| 9F2247 | 5 PLUG-PIPE (1/8-27-THD) | 9 | |
| 6N9133 | 6 GASKET-PLATE | 2 | |
| 4N4178 | 7 PLATE-BLOCK | 2 | |
| 4N0693 | 8 PLUG-TAPERLOCK (1-1/2-12-THD)(38.10MM OD) | 3 | |
| 4N0683 | 9 DOWEL | 4 | |
| 4N9916 | 10 BOLT | 8 | |
| 3B0645 | 11 PLUG-CUP (32.08-MM OD) | 1 | |
| 6L4428 | 12 STUD-TAPERLOCK (3/8-16X4.01-IN) | 3 | |
| 2M9780 | 13 SEAL-O-RING | 4 | |
| 7M7410 | 14 PLUG-PIPE | 6 | |
| 8M8283 | 15 SEAL-O-RING | 2 | |
| 3S6605 | 16 PLUG-CUP | 2 | |
| 9S4190 | 17 PLUG-O-RING (7/8-14-THD) | 4 | |
| 4W6061 | SLEEVE | ||
| 4W4588 | SLEEVE-LIFTER BORE | ||
| 2W3815 | INSERT-LINER SEAT (1.605-MM THK) | ||
| 6I4363 | INSERT-LINER SEAT (1.555-MM THK) | ||
| 6I4364 | INSERT-LINER SEAT (1.655-MM THK) | ||
| 5N0093 | INSERT-LINER SEAT (2.71-MM THK) | ||
| 6I4365 | INSERT-LINER SEAT (2.66-MM THK) | ||
| 6I4366 | INSERT-LINER SEAT (2.76-MM THK) |
