System And Components
130-5134 LINES GP-FUELType 1
Group No: 130-5134
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8L2786 | 1 SEAL-O-RING | 3 | |
| 1022240 | 2 SENSOR GP-TEMPERATURE (3-PIN)(FUEL) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN)(FUEL TEMPERATURE SENSOR) | 1 | |
| 3E3371 | WEDGE-RECEPTACLE LOCK (3-PIN) | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 9X1813 | SLEEVE | ||
| 6V5049 | 3 SEAL-O-RING | 20 | |
| 9S3232 | 4 CLIP | 1 | |
| 8M2773 | 5 CLIP (LOOP) | 5 | |
| 0S1594 | 6 BOLT (3/8-16X1-IN) | 1 | |
| 9S8752 | 7 NUT-FULL (3/8-16-THD) | 4 | |
| 9X6458 | 8 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 5M2894 | 9 WASHER-HARD (10.2X18.5X2.5-MM THK) | 14 | |
| 1027535 | 10 VALVE GP-CHECK (FUEL) | 1 | |
| 9S8004 | 11 PLUG (9/16-18-THD) | 4 | |
| 2R6806 | 12 CONNECTOR | 6 | |
| 6P5353 | 13 HOSE AS | 3 | |
| 8M0505 | 14 ADAPTER | 1 | |
| 9G8916 | 15 HOSE AS | 1 | |
| 3N7156 | 16 HOSE AS | 1 | |
| 6K9194 | 17 ELBOW | 2 | |
| 8M0506 | 18 ADAPTER-O-RING | 1 | |
| 3B1915 | 19 BOLT (3/8-16X1.375-IN) | 1 | |
| 0910081 | 20 SPACER (10.5X20X10-MM THK) | 2 | |
| 1L3613 | 21 CLIP | 1 | |
| 7D7233 | 22 CLIP (LOOP) | 3 | |
| 0S1591 | 23 BOLT (3/8-16X1.5-IN) | 2 | |
| 0308188 | 24 CONNECTOR | 1 | |
| 2W3038 | 25 BRACKET AS | 1 | |
| 0307947 | 26 ADAPTER-ELBOW | 3 | |
| 1B2790 | 27 BOLT (5/16-18X1.375-IN) | 1 | |
| 5P8245 | 28 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 0L1351 | 29 BOLT (3/8-16X0.875-IN) | 2 | |
| 8M0547 | 30 ELBOW-FLARED (SWIVEL) | 1 | |
| 0308144 | 31 REDUCER-FLARED | 1 | |
| 1P1441 | 32 NUT-FLARED (3/4-16-THD) | 1 | |
| 2P7214 | 33 ADAPTER-ELBOW | 2 | |
| 7N2638 | 34 HOSE AS | 1 | |
| 6N8968 | 35 HOSE AS | 1 | |
| 7G1971 | 36 HOSE AS | 1 | |
| 4B4043 | 37 BOLT (5/8-11X1.375-IN) | 4 | |
| 5P8247 | 38 WASHER-HARD (17X32X3.5-MM THK) | 4 | |
| 1R0749 | 39 FILTER-FUEL (ADVANCED EFFICIENCY) | 2 | |
| 0L2070 | 40 BOLT (3/8-16X2.25-IN) | 1 | |
| 0S1588 | 41 BOLT (3/8-16X1.25-IN) | 3 | |
| 4D7733 | 42 CLIP (LOOP) | 1 | |
| 9M1974 | 43 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 6N4414 | 44 COVER-FILTER BASE | 1 | |
| 1P0436 | 45 GASKET (FUEL PRIMING PUMP) | 1 | |
| 7B2742 | 46 BOLT (1/4-20X1.25-IN) | 1 | |
| 5P0537 | 47 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 9S4191 | 48 PLUG (9/16-18-THD) | 4 | |
| 9X0262 | 49 ADAPTER | 1 | |
| 6V5048 | 50 SEAL-O-RING | 2 | |
| 6N2946 | 51 BASE AS-FUEL FILTER | 1 | |
| 3W9670 | 52 BOSS | 1 | |
| 0L1143 | 53 BOLT (3/8-16X2.5-IN) | 1 | |
| 1284811 | 54 BRACKET AS | 1 | |
| 4K9097 | NUT-WELD (5/16-18-THD) | 2 | |
| 0S1619 | 55 BOLT (3/8-16X3-IN) | 1 | |
| 6N3797 | 56 JUNCTION BLOCK | 1 | |
| 0530700 | 57 TEE-SWIVEL (FLARED) | 1 | |
| 0S1595 | 58 BOLT (1/2-13X1.25-IN) | 2 | |
| 1230555 | 59 MANIFOLD | 1 | |
| 1B9575 | 60 BOLT (5/16-18X1.56-IN) | 2 | |
| 6N3877 | 61 HOSE AS | 1 | |
| 1619930 | 62 SENSOR GP-PRESSURE (FUEL) | 1 |
