System And Components
381-9080 CYLINDER BLOCK GPS/N XLG1-UP; FPL1-UP
Group No: 381-9080
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N1650 | 1 DOWEL | 4 | |
| 6I4613 | 2 PLATE-SPACER | 2 | |
| 6N9133 | 3 GASKET-PLATE | 2 | |
| 7C9614 | 4 PLUG-TAPERLOCK (1-5/8-12-THD) | 3 | |
| 1118606 | 5 BOLT-SPECIAL (OIL JET) | 8 | |
| 1103779 | 6 CYLINDER BLOCK AS | 1 | |
| 1554010 | 7 TUBE AS-OIL JET | 8 | |
| 3557181 | 8 STUD (3/8-16X3.5-IN) | 1 | |
| 2M9780 | 9 SEAL-O-RING | 2 | |
| 3B0645 | 10 PLUG-CUP (32.08-MM OD) | 1 | |
| 3S6605 | 11 PLUG-CUP | 2 | |
| 4N0683 | 12 DOWEL | 4 | |
| 6L4428 | 13 STUD-TAPERLOCK (3/8-16X4.01-IN) | 3 | |
| 7W6534 | 14 PLUG-PIPE | 5 | |
| 8M8283 | 15 SEAL-O-RING | 2 | |
| 8T6757 | 16 PLUG-PIPE | 7 | |
| 8T6763 | 17 PLUG-PIPE (1/4-18-THD) | 4 | |
| 8T6764 | 18 PLUG-PIPE (1/8-27-THD) | 1 | |
| 9S4190 | 19 PLUG-O-RING (7/8-14-THD) | 2 |
