System And Components
351-1764 WIRING GP-ENGINES/N SSM1-UP
Group No: 351-1764
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2042518 | 1 SENSOR GP-LIQUID LEVEL (COOLANT) | 2 | |
| 2746719 | 2 SENSOR GP-PRESSURE (3-PIN)(OIL PRESSURE) | 1 | |
| 2746719 | 2A SENSOR GP-PRESSURE (3-PIN)(FUEL PRESSURE) | 1 | |
| 2883783 | 3 SENSOR-TEMPERATURE (AIR INLET MANIFOLD) | 1 | |
| 2883783 | 3A SENSOR-TEMPERATURE (ENGINE OIL) | 1 | |
| 2883783 | 3B SENSOR-TEMPERATURE (JACKET WATER) | 1 | |
| 2883783 | 3C SENSOR-TEMPERATURE (FUEL) | 1 | |
| 2746721 | 4 SENSOR GP-PRESSURE (AIR INLET MANIFOLD) | 1 | |
| 4747471 | 5 HARNESS AS-ENGINE | 1 | |
| 3034649 | 6 CLIP (LADDER) | 1 | |
| 2697678 | 7 CLIP | 1 | |
| 0S0509 | 8 BOLT (3/8-16X0.75-IN) | 4 | |
| 0S1594 | 9 BOLT (3/8-16X1-IN) | 1 | |
| 1046202 | 10 CLIP (LADDER) | 1 | |
| 1325789 | 11 CLIP (LADDER) | 3 | |
| 2062423 | 12 SADDLE-MOUNTING | 1 | |
| 2190669 | 13 SEAL-O-RING | 1 | |
| 2287100 | 14 SEAL-O-RING | 4 | |
| 3101898 | 15 CLIP (LADDER) | 1 | |
| 3169351 | 16 MOUNTING-CABLE TIE | 2 | |
| 9S8750 | 17 NUT-FULL (1/4-20-THD) | 1 | |
| 3523964 | 18 CLIP (LADDER) | 1 | |
| 3523968 | 19 CLIP (LADDER) | 2 | |
| 4P7581 | 20 CLIP (LADDER) | 4 | |
| 4P8134 | 21 CLIP (LADDER) | 2 | |
| 5M2894 | 22 WASHER-HARD (10.2X18.5X2.5-MM THK) | 9 | |
| 5P6887 | 23 GROMMET | 1 | |
| 7K1181 | 24 STRAP-CABLE | 33 | |
| 9S8752 | 25 NUT-FULL (3/8-16-THD) | 2 | |
| 5P0537 | 26 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 3523967 | 27 CLIP (LADDER) | 1 | |
| 4P5918 | 28 CLIP | 1 | |
| 1A2029 | 29 BOLT (3/8-16X1.125-IN) | 1 | |
| 1J8668 | 30 STUD-TAPERLOCK (3/8-16X1.97-IN) | 1 | |
| 6V8801 | 31 NUT (3/8-16-THD) | 1 | |
| 0S1615 | 32 BOLT (1/4-20X0.75-IN) | 1 |
