System And Components
470-7615 EXHAUST GPS/N DK61-UP
Group No: 470-7615
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5L3773 | 1 GASKET-EXHAUST ELBOW | 1 | |
| 1139848 | 2 GASKET | 3 | |
| 1665025 | 3 STRAP | 2 | |
| 2111009 | 4 ADAPTER AS | 1 | |
| 4703045 | 5 PIPE AS-EXHAUST | 1 | |
| 1454933 | FLANGE | 2 | |
| 4707611 | 6 MUFFLER AS | 1 | |
| 1430857 | PLUG | 2 | |
| 1454933 | FLANGE | 2 | |
| 4707612 | 7 BRACKET AS | 2 | |
| 1665025 | STRAP | 1 | |
| 4707614 | 8 KIT-INSULATION | 1 | |
| 1679181 | 9 PIPE AS | 1 | |
| 5S7383 | 10 BOLT (3/8-16X1.75-IN) | 8 | |
| 6V8801 | 11 NUT (3/8-16-THD) | 8 | |
| 7X2563 | 12 BOLT (M20X2.5X60-MM) | 24 | |
| 8T4121 | 13 WASHER-HARD (11X21X2.5-MM THK) | 16 | |
| 8T4123 | 14 WASHER (22X35X3.5-MM THK) | 48 | |
| 8T4131 | 15 NUT (M20X2.5-THD) | 24 | |
| 8T4133 | 16 NUT (M10X1.5-THD) | 8 | |
| 8T4136 | 17 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4185 | 18 BOLT (M10X1.5X50-MM) | 4 | |
| 8T4896 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 16 |
