System And Components
373-9473 ALARM GP -REMOTES/N DK61-UP
Group No: 373-9473
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5H4871 | 1 PLUG | 2 | |
| 7G9730 | 2 LAMP AS (120-VOLT, 3-WATT) | 1 | |
| 6V8367 | LOCKWASHER | 1 | |
| 6V8382 | NUT-HEX (11/16-27-THD) | 1 | |
| 3166409 | LAMP AS (10 TO 32-VOLT) | 1 | |
| 5P5694 | TERMINAL-BLADE (14-GA TO 16-GA) | 2 | |
| 6V8367 | LOCKWASHER | 1 | |
| 6V8382 | NUT-HEX (11/16-27-THD) | 1 | |
| 1003245 | 3 LAMP (24-VOLT) | 1 | |
| 2449613 | 4 GASKET | 1 | |
| 2452987 | 5 FILM-IDENTIFICATION (CAT) | 1 | |
| 2721065 | 6 PLATE | 1 | |
| 2721079 | 7 LID | 1 | |
| 3511718 | 8 BOX AS | 1 | |
| 2057047 | INSERT-THREADED (M4X0.7-THD) | 8 | |
| 3585994 | 9 MODULE GP-ALARM | 1 | |
| 3739468 | 10 BLOCK AS-TERMINAL | 1 | |
| 3739469 | 11 HARNESS AS-ALARM | 1 | |
| 5P6001 | TUBE-HEAT SHRINK (4.75-MM DIA)(0.1-M) | ||
| 7K1181 | STRAP-CABLE | 10 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 5 | |
| 8T8737 | PLUG-SEAL | 3 | |
| 1257876 | TUBE-HEAT SHRINK (17.78-MM DIA)(5-CM) | ||
| 1285669 | TERMINAL-BLADE (14-GA TO 16-GA) | 2 | |
| 2L8074 | TERMINAL-RING (14-GA TO 16-GA, NO. 6 SCREW) | 2 | |
| 1552265 | KIT-CONNECTING PLUG (8-PIN) | 1 | |
| 1230707 | 12 SCREW-HEX SOCKET (M4X0.7X20-MM) | 8 | |
| 1514977 | 13 WASHER (4.445X9.525X1.092-MM THK) | 8 | |
| 4B2041 | 14 NUT (6-32-THD) | 2 | |
| 6V8225 | 15 NUT (M6X1-THD) | 4 | |
| 8D2676 | 16 SWITCH AS-TOGGLE (SINGLE POLE)(ALARM) | 1 | |
| 8T4205 | 17 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 9B7233 | 18 LOCKWASHER | 2 | |
| 9X8256 | 19 WASHER (6.6X12X2-MM THK) | 2 | |
| 8C7524 | 20 SEAL (115.5-CM EACH) |
