System And Components
463-2240 BOX GP-CONTROL PANELS/N DK61-UP
Group No: 463-2240
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1435099 | 1 INSULATOR | 6 | |
| 4986246 | 2 MOUNTING GP-BOX | 1 | |
| 3445675 | 3 NUT (M10X1.5-THD) | 4 | |
| 4404429 | 4 SUPPORT GP-GENERATOR BOX | 1 | |
| 4632228 | 5 PLATE AS | 1 | |
| 4632239 | 6 PLATE AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 24 | |
| 7T1099 | LINK | 4 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 6 | |
| 4632246 | 7 PANEL GP-ELECTRONIC | 1 | |
| 3E6600 | SEAL (34-CM) | ||
| 2354451 | BOLT-FLANGE HEAD (M6X1X16-MM) | 8 | |
| 4632245 | PLATE AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 33 | |
| 4632248 | 8 COVER GP-ACCESS | 1 | |
| 4632249 | 9 COVER GP-ACCESS | 1 | |
| 4787388 | 10 BAR | 3 | |
| 5P4116 | 11 WASHER-HARD (8.8X20.5X2-MM THK) | 2 | |
| 8T4191 | 12 BOLT (M10X1.5X16-MM) | 6 | |
| 8T4121 | 13 WASHER-HARD (11X21X2.5-MM THK) | 16 | |
| 8T4185 | 14 BOLT (M10X1.5X50-MM) | 2 | |
| 8T4186 | 15 BOLT (M10X1.5X40-MM) | 4 | |
| 8T4908 | 16 BOLT (M8X1.25X25-MM) | 2 | |
| 4447168 | 17 COVER | 1 | |
| 2V8259 | 18 GROMMET | 1 | |
| 4F8711 | 19 PLUG-BUTTON | 1 | |
| 2354451 | 20 BOLT-FLANGE HEAD (M6X1X16-MM) | 2 | |
| 1426868 | 21 SEAL (118-CM) |
