System And Components
482-9522 ALTERNATOR GP-CHARGING24-VOLT,120-AMPRERE
Group No: 482-9522
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E5239 | 1 RELAY AS (24-VOLT) | 1 | |
| 3S2093 | 2 STRAP-CABLE | 1 | |
| 4387314 | 3 STUD | 1 | |
| 0996418 | 4 NUT (M6X1-THD) | 1 | |
| 4815508 | 5 BOLT-FLANGE HEAD | 2 | |
| 1013805 | 6 BOLT (M8X1.25X90-MM) | 1 | |
| 1783336 | 7 NUT-HEX FLANGE (M8X1.25-THD) | 1 | |
| 4479087 | 8 BUSHING | 1 | |
| 4610095 | 9 ISOLATOR AS | 1 | |
| 4626343 | 10 RESISTOR | 1 | |
| 4829523 | 11 ALTERNATOR AS (24-VOLT) | 1 | |
| 4829533 | KIT-PULLEY | 1 | |
| 4829528 | 12 BRACKET-SUPPORT | 1 | |
| 4829529 | 13 BRACKET-SUPPORT | 1 | |
| 4829530 | 14 BOLT-HEAD (M16X1X80-MM) | 2 | |
| 4639172 | 15 BOLT (M10X1.5X70-MM) | 1 | |
| 4829532 | 16 BOLT-HEAD | 1 | |
| 4P7581 | 17 CLIP (LADDER) | 1 |
