System And Components
482-9538 ALTERNATOR GP-CHARGING24-VOLT,160-AMPRERE
Group No: 482-9538
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E5239 | 1 RELAY AS (24-VOLT) | 1 | |
| 3S2093 | 2 STRAP-CABLE | 1 | |
| 4387314 | 3 STUD | 1 | |
| 0996418 | 4 NUT (M6X1-THD) | 1 | |
| 4813723 | 5 BOLT-HEAD | 1 | |
| 1783336 | 6 NUT-HEX FLANGE (M8X1.25-THD) | 3 | |
| 1757141 | 7 NUT-HEX FLANGE (M10X1.5-THD) | 1 | |
| 4610095 | 8 ISOLATOR AS | 1 | |
| 4626343 | 9 RESISTOR | 1 | |
| 4639172 | 10 BOLT (M10X1.5X70-MM) | 1 | |
| 5001200 | 11 BOLT-FLANGE HEAD | 2 | |
| 4829530 | 12 BOLT-HEAD (M16X1X80-MM) | 2 | |
| 4829536 | 13 BOLT-HEAD | 1 | |
| 4829539 | 14 BRACKET-SUPPORT | 1 | |
| 4829540 | 15 BRACKET-SUPPORT | 1 | |
| 4829541 | 16 ALTERNATOR AS (24-VOLT, 160-AMPERE) | 1 | |
| 4829542 | 16A KIT-PULLEY | 1 | |
| 4P7581 | 17 CLIP (LADDER) | 1 | |
| 6I0254 | 18 BOLT (M8X1.25X30-MM) | 2 | |
| 5382045 | 19 GUARD-ALTERNATOR | 1 |
