System And Components
462-6123 LINES GP-ENGINE OILType 2
Group No: 462-6123
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W2447 | 1 ADAPTER-OUTLET | 1 | |
| 2W1053 | 2 PLUG | 1 | |
| 2W1635 | 3 SPRING | 1 | |
| 4W4313 | 6 ADAPTER | 1 | |
| 4W4677 | 7 TUBE | 1 | |
| 6B9202 | 8 SPRING | 2 | |
| 7N7697 | 9 PLUNGER AS | 2 | |
| 7M1808 | DOWEL | 1 | |
| 8N2929 | 10 COVER | 2 | |
| 8W2398 | 11 FLANGE | 1 | |
| 9X6772 | 12 STRAP-CABLE | 1 | |
| 1008075 | 13 CLAMP AS | 2 | |
| 1113820 | 14 RING-RETAINING | 1 | |
| 1244273 | 15 VALVE-BYPASS | 1 | |
| 1363296 | 16 FLANGE | 1 | |
| 1435184 | 17 PLUG-ADAPTER (3/4-14-THDX3/8-16-THD) | 1 | |
| 1467359 | 18 TUBE | 1 | |
| 1506612 | 19 ELBOW-OUTLET | 1 | |
| 1539963 | 20 RING | 2 | |
| 1916695 | 21 PLATE | 1 | |
| 2377623 | 22 SEAL-O-RING | 2 | |
| 2401919 | 23 TUBE AS | 1 | |
| 2445867 | 24 ELBOW | 1 | |
| 2456848 | 25 CLAMP AS | 4 | |
| 2474806 | 26 ELBOW | 1 | |
| 2982410 | 27 BRACKET | 1 | |
| 3594123 | 28 ADAPTER | 1 | |
| 3617097 | 29 RING | 1 | |
| 3617098 | 30 FLANGE | 1 | |
| 3654215 | 31 ADAPTER | 1 | |
| 0908747 | 32 SPACER (11X19X32-MM THK) | 1 | |
| 0L1143 | 33 BOLT (3/8-16X2.5-IN) | 4 | |
| 1653931 | 34 BOLT (3/8-16X1.75-IN) | 8 | |
| 0S1588 | 35 BOLT (3/8-16X1.25-IN) | 12 | |
| 0S1590 | 36 BOLT (3/8-16X2-IN) | 2 | |
| 1653929 | 37 BOLT (3/8-16X1.5-IN) | 6 | |
| 0T0065 | 38 BOLT (3/8-16X3.5-IN) | 9 | |
| 0T0573 | 39 BOLT (3/8-16X2.75-IN) | 1 | |
| 1092332 | 40 SEAL-O-RING | 4 | |
| 1686890 | 41 CLIP (SLOT) | 1 | |
| 1686891 | 42 CLIP (TAB) | 1 | |
| 1A2029 | 43 BOLT (3/8-16X1.125-IN) | 8 | |
| 2287097 | 44 SEAL-O-RING | 1 | |
| 3P0653 | 45 SEAL-O-RING | 1 | |
| 3P0655 | 46 SEAL-O-RING | 1 | |
| 3S1546 | 47 NUT-FULL (7/16-14-THD) | 6 | |
| 4F8965 | 48 BOLT (7/16-14X1.125-IN) | 6 | |
| 4P7581 | 49 CLIP (LADDER) | 1 | |
| 5M2894 | 50 WASHER-HARD (10.2X18.5X2.5-MM THK) | 21 | |
| 5P4892 | 51 SEAL-O-RING | 3 | |
| 5P5846 | 52 SEAL-O-RING | 1 | |
| 5P8244 | 53 WASHER-HARD (12X22.5X2.5-MM THK) | 12 | |
| 6B0933 | 54 SPACER (10.31X19.05X6.35-MM THK) | 4 | |
| 6J2244 | 55 SEAL-O-RING | 1 | |
| 6V1574 | 56 GROMMET | 1 | |
| 6V3908 | 57 SEAL-O-RING | 1 | |
| 6V4368 | 58 SEAL-O-RING | 4 | |
| 6V4589 | 59 SEAL-O-RING | 2 | |
| 6V5048 | 60 SEAL-O-RING | 1 | |
| 2385080 | 61 SEAL-O-RING | 1 | |
| 8C3107 | 62 SEAL-O-RING | 1 | |
| 8C3445 | 63 CAP-DUST | 1 | |
| 8C3446 | 64 VALVE-SAMPLING | 1 | |
| 8T6762 | 65 PLUG-PIPE (1/2-14-THD) | 1 | |
| 9S4185 | 66 PLUG (3/4-16-THD) | 1 | |
| 9S4190 | 67 PLUG-O-RING (7/8-14-THD) | 2 | |
| 9S8752 | 68 NUT-FULL (3/8-16-THD) | 1 | |
| 9X6458 | 69 WASHER-HARD (10.2X22.5X3-MM THK) | 4 |
