System And Components
490-3803 LINES GP-ENGINE OIL -FILTERAN ATTACHMENT
Group No: 490-3803
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4W4313 | 1 ADAPTER | 1 | |
| 4W4677 | 2 TUBE | 1 | |
| 9X6772 | 3 STRAP-CABLE | 1 | |
| 1008075 | 4 CLAMP AS | 2 | |
| 1113820 | 5 RING-RETAINING | 1 | |
| 2401919 | 6 TUBE AS | 1 | |
| 2982410 | 7 BRACKET | 1 | |
| 3617097 | 8 RING | 1 | |
| 3617098 | 9 FLANGE | 1 | |
| 0908747 | 10 SPACER (11X19X32-MM THK) | 1 | |
| 1653931 | 11 BOLT (3/8-16X1.75-IN) | 4 | |
| 0S1590 | 12 BOLT (3/8-16X2-IN) | 2 | |
| 1653929 | 13 BOLT (3/8-16X1.5-IN) | 2 | |
| 0T0065 | 14 BOLT (3/8-16X3.5-IN) | 1 | |
| 0T0573 | 15 BOLT (3/8-16X2.75-IN) | 1 | |
| 1092332 | 16 SEAL-O-RING | 4 | |
| 1686890 | 17 CLIP (SLOT) | 1 | |
| 1686891 | 18 CLIP (TAB) | 1 | |
| 1A2029 | 19 BOLT (3/8-16X1.125-IN) | 2 | |
| 3S1546 | 20 NUT-FULL (7/16-14-THD) | 2 | |
| 4F8965 | 21 BOLT (7/16-14X1.125-IN) | 2 | |
| 4P7581 | 22 CLIP (LADDER) | 1 | |
| 5M2894 | 23 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 5P4892 | 24 SEAL-O-RING | 2 | |
| 5P8244 | 25 WASHER-HARD (12X22.5X2.5-MM THK) | 4 | |
| 6V1574 | 26 GROMMET | 1 | |
| 6V5048 | 27 SEAL-O-RING | 1 | |
| 8C3445 | 28 CAP-DUST | 1 | |
| 8C3446 | 29 VALVE-SAMPLING | 1 | |
| 9S8752 | 30 NUT-FULL (3/8-16-THD) | 1 | |
| 9X6458 | 31 WASHER-HARD (10.2X22.5X3-MM THK) | 4 |
