System And Components
469-0133 LINES GP-FUEL INJECTION -SERVICE, RHType 2
Group No: 469-0133
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P0692 | 1 CLAMP AS | 4 | |
| 1081434 | GROMMET | 1 | |
| 7C7682 | 2 ADAPTER-FUEL MANIFOLD (RH) | 1 | |
| 7C7683 | 3 ADAPTER-FUEL MANIFOLD (LH) | 1 | |
| 7C8246 | 4 SPACER (10.5X20X24-MM THK) | 2 | |
| 7E3921 | 5 VALVE-CHECK | 1 | |
| 9N4053 | 6 SPRING | 1 | |
| 1070568 | 7 BRACKET | 1 | |
| 1145477 | 8 PLUNGER-VALVE | 1 | |
| 1158082 | 9 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 1204351 | 10 PLATE | 1 | |
| 1537487 | 11 ELBOW | 1 | |
| 3498519 | 12 ELBOW AS | 1 | |
| 6V9003 | ELBOW | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3866213 | 13 CONNECTOR AS | 1 | |
| 6K3607 | CONNECTOR | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 4243585 | 14 HOSE AS | 1 | |
| 4780107 | 15 HOSE AS | 1 | |
| 4780108 | 16 HOSE AS | 1 | |
| 4805510 | 17 HOSE AS | 1 | |
| 4805511 | 18 BRACKET | 1 | |
| 4858914 | 19 HOSE & TUBE AS | 1 | |
| 4858915 | 20 TUBE AS | 1 | |
| 0307982 | 21 UNION-FLARED | 1 | |
| 0L1143 | 22 BOLT (3/8-16X2.5-IN) | 2 | |
| 0L2070 | 23 BOLT (3/8-16X2.25-IN) | 1 | |
| 1653929 | 24 BOLT (3/8-16X1.5-IN) | 2 | |
| 0T0065 | 25 BOLT (3/8-16X3.5-IN) | 2 | |
| 1003237 | 26 GROMMET | 1 | |
| 1124387 | 27 ELBOW | 1 | |
| 1364992 | 28 SPACER (11X20X40-MM THK) | 1 | |
| 1A2029 | 29 BOLT (3/8-16X1.125-IN) | 3 | |
| 1D4539 | 30 BOLT (5/16-18X2.5-IN) | 1 | |
| 1D4541 | 31 BOLT (5/16-18X3-IN) | 1 | |
| 2287091 | 32 SEAL-O-RING | 2 | |
| 2385081 | 33 SEAL-O-RING | 1 | |
| 2815975 | 34 ELBOW AS | 4 | |
| 6V8626 | ELBOW | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3095130 | 35 PLUG AS | 1 | |
| 9S4182 | PLUG (7/16-20-THD) | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3104947 | 36 CLIP (SLOT) | 2 | |
| 3104948 | 37 CLIP (TAB) | 2 | |
| 3537952 | 38 GROMMET | 1 | |
| 3G8047 | 39 GROMMET | 2 | |
| 5M2894 | 40 WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 6V9845 | 41 TEE-SWIVEL | 1 | |
| 8T1887 | 42 CLIP (SLOT) | 1 | |
| 8T1888 | 43 CLIP (TAB) | 1 | |
| 8T1897 | 44 CLIP (SLOT) | 1 | |
| 8T1898 | 45 CLIP (TAB) | 1 | |
| 9M1974 | 46 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9S8752 | 47 NUT-FULL (3/8-16-THD) | 3 | |
| 9X6458 | 48 WASHER-HARD (10.2X22.5X3-MM THK) | 10 |
