System And Components
539-2722 PUMP GP-FUEL PRIMING -RHAN ATTACHMENT
Group No: 539-2722
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1N2897 | 1 PLATE AS | 1 | |
| 4P0692 | 2 CLAMP AS | 6 | |
| 1081434 | GROMMET | 1 | |
| 7N8599 | 3 PUMP GP-FUEL PRIMING | 1 | |
| 8N7054 | 4 SUPPORT | 1 | |
| 9M0766 | 5 BRACKET | 1 | |
| 9N1752 | 6 SPRING | 1 | |
| 0922467 | 7 SPACER (10.5X2X45-MM THK) | 1 | |
| 1163266 | 8 BRACKET | 1 | |
| 1204351 | 9 PLATE | 1 | |
| 1277104 | 10 BRACKET | 1 | |
| 1277105 | 11 ADAPTER | 1 | |
| 3095131 | 12 PLUG AS | 1 | |
| 9S8006 | PLUG (7/8-14-THD) | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3535133 | 13 ELBOW AS | 2 | |
| 0307949 | ELBOW | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3650577 | 14 CONNECTOR AS | 1 | |
| 6V4362 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3650578 | 15 CONNECTOR AS | 1 | |
| 2P7636 | CONNECTOR (3/4-16 STR-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3847876 | 16 BRACKET | 1 | |
| 5160535 | 17 TUBE AS | 1 | |
| 5191341 | 18 HOSE & TUBE AS | 1 | |
| 5392723 | 19 HOSE AS | 1 | |
| 0L1143 | 20 BOLT (3/8-16X2.5-IN) | 3 | |
| 0L2070 | 21 BOLT (3/8-16X2.25-IN) | 2 | |
| 1653929 | 22 BOLT (3/8-16X1.5-IN) | 1 | |
| 0S1594 | 23 BOLT (3/8-16X1-IN) | 3 | |
| 0S1595 | 24 BOLT (1/2-13X1.25-IN) | 2 | |
| 1327551 | 25 SPACER (11X19X6-MM THK) | 1 | |
| 1A2029 | 26 BOLT (3/8-16X1.125-IN) | 2 | |
| 1A5964 | 27 BOLT (3/8-16X4.5-IN) | 1 | |
| 2H9523 | 28 GROMMET | 1 | |
| 3537952 | 29 GROMMET | 2 | |
| 4B9782 | 30 BALL | 1 | |
| 4M2442 | 31 BOLT (1/2-13X12.32-IN) | 2 | |
| 4P7581 | 32 CLIP (LADDER) | 3 | |
| 5M2894 | 33 WASHER-HARD (10.2X18.5X2.5-MM THK) | 16 | |
| 5P8245 | 34 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8B9725 | 35 BOSS | 2 | |
| 8N3480 | 36 CLIP | 1 | |
| 8T1897 | 37 CLIP (SLOT) | 2 | |
| 8T1898 | 38 CLIP (TAB) | 2 | |
| 8T2270 | 39 CONNECTOR-EXTENSION | 1 | |
| 9S8752 | 40 NUT-FULL (3/8-16-THD) | 5 | |
| 9X6458 | 41 WASHER-HARD (10.2X22.5X3-MM THK) | 1 |
