394-8291 PANEL GP-INSTRUMENTAN ATTACHMENT

Group No: 394-8291

Part Number	Part Name	Qty
2W4480	1 BOOT-SWITCH	1
4W5972	2 KNOB	1
8C6123	3 NUT (1/4-40-THD)	1
9W0073	4 SWITCH AS-PUSH BUTTON (ALARM SILENCE)	1
1005566	5 BEZEL	4
1185075	6 LAMP (12-VOLT)	6
1229457	7 POTENTIOMETER (ENGINE SPEED)	1
1239694	8 HORN	1
1538531	9 FILM-IDENTIFICATION (CONTROL PANEL)	1
1552556	10 HARNESS AS-BOX	1
2L8075	TERMINAL-RING (14-GA TO 16-GA, NO. 8 SCREW)	1
1552265	KIT-CONNECTING PLUG (8-PIN)	3
5P4571	TERMINAL-BLADE (14-GA TO 16-GA)	7
5P5618	TERMINAL-BLADE (10-GA TO 12-GA)	7
6V2689	TUBE-HEAT SHRINK (6.35-MM DIA)(0.6-M)
7E8866	TERMINAL-BLADE (14-GA TO 16-GA)	12
8N1534	RECEPTACLE AS-CONNECTOR (20-PIN)	1
8N1536	NUT (1-5/8-18-THD)	1
8T8730	SOCKET-CONNECTOR (16-GA TO 20-GA)	35
8T8737	PLUG-SEAL	41
8T9834	PLUG AS-CONNECTOR (40-PIN)	1
3E4367	RING-RETAINING	1
3E8557	BOLT (M5X0.8X39.37-MM)	1
9X3132	SEAL-CONNECTOR (40-PIN)	2
9X6856	PIN-CONNECTOR (16-GA TO 18-GA)	8
1135183	SOCKET-LAMP	6
1135184	TERMINAL-RECEPTACLE (16-GA TO 18-GA)	12
2L8075	TERMINAL-RING (14-GA TO 16-GA, NO. 8 SCREW)	1
1552576	11 FILM-CONTROL PANEL (LOCOMOTIVE)	1
1552577	12 PLATE AS	1
1552597	13 BRACKET	1
1666929	14 MODULE GP-QUAD GAUGE (EXHAUST GAS TEMP, FILTERS)	1
1666937	15 MODULE GP-QUAD GAUGE (AIR INLET,AFTERCOOLER,ENG OIL)	1
1586255	16 CONTROL GP-ENGINE MONITORING	1
1586638	17 SWITCH AS-ROCKER	1
3E8775	SWITCH AS (24-VOLT)(CLEAR, MODE)	1
3E8825	LAMP (24-VOLT)	2
1552705	ACTUATOR	1
1586639	18 SWITCH AS-ROCKER	1
3E8768	SWITCH AS (24-VOLT)(SCROLL)	1
3E8825	LAMP (24-VOLT)	1
1552706	ACTUATOR	1
1586640	19 SWITCH AS-ROCKER	1
3E8858	SWITCH AS (ENGINE PARAMETER, RH, LH)	1
3E8825	LAMP (24-VOLT)	2
1552705	ACTUATOR	1
1666936	20 MODULE GP-QUAD GAUGE (BATTERY, COOLANT, FUEL, OIL)	1
4B4274	21 WASHER (5.5X13X1.2-MM THK)	16
6V8225	22 NUT (M6X1-THD)	2
6V8378	23 NUT (10-32-THD)	16
7U4891	24 SCREW (10-32X1-IN)	16
8T3991	25 SCREW-BUTTON HEAD (M6X1X20-MM)	2
9X8267	26 WASHER (6.6X12X2-MM THK)	2
