System And Components
476-9327 LINES GP-TURBOCHARGER OILAN ATTACHMENT
Group No: 476-9327
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P0692 | 1 CLAMP AS | 4 | |
| 1081434 | GROMMET | 1 | |
| 8U4791 | 2 WASHER (11X21X8-MM THK) | 2 | |
| 2528374 | 3 GASKET | 2 | |
| 1664116 | 4 SPACER (10X16X20-MM THK) | 2 | |
| 3726137 | 5 TUBE | 1 | |
| 3726138 | 6 TUBE | 1 | |
| 4574005 | 7 TUBE AS | 1 | |
| 4574006 | 8 TUBE AS | 1 | |
| 4576036 | 9 BRACKET | 1 | |
| 3709841 | 10 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 4574004 | 11 TUBE AS | 1 | |
| 0L1143 | 12 BOLT (3/8-16X2.5-IN) | 4 | |
| 0L2070 | 13 BOLT (3/8-16X2.25-IN) | 2 | |
| 0S1588 | 14 BOLT (3/8-16X1.25-IN) | 1 | |
| 1003237 | 15 GROMMET | 3 | |
| 1252784 | 16 ELBOW | 2 | |
| 0S1594 | 17 BOLT (3/8-16X1-IN) | 1 | |
| 0S1619 | 18 BOLT (3/8-16X3-IN) | 2 | |
| 2P1293 | 19 LOCKNUT (1-3/16-12-THD) | 1 | |
| 3048000 | 20 ELBOW AS | 2 | |
| 2270057 | ELBOW | 1 | |
| 2287091 | 20A SEAL-O-RING | 1 | |
| 2287105 | 20B SEAL-O-RING | 1 | |
| 2287092 | 21 SEAL-O-RING | 5 | |
| 3133492 | 22 PLUG AS | 1 | |
| 9S4190 | PLUG-O-RING (7/8-14-THD) | 1 | |
| 2385081 | 22A SEAL-O-RING | 1 | |
| 2385081 | 23 SEAL-O-RING | 1 | |
| 3537953 | 24 GROMMET | 2 | |
| 3B1915 | 25 BOLT (3/8-16X1.375-IN) | 1 | |
| 5M2894 | 26 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 6V5134 | 27 SEAL-O-RING | 4 | |
| 6V9032 | 28 TEE-O-RING | 1 | |
| 8T1887 | 29 CLIP (SLOT) | 3 | |
| 8T1888 | 30 CLIP (TAB) | 3 | |
| 8T1889 | 31 CLIP (SLOT) | 2 | |
| 8T1890 | 32 CLIP (TAB) | 2 | |
| 9S8752 | 33 NUT-FULL (3/8-16-THD) | 3 | |
| 6V9160 | 34 TEE-FACE SEAL | 1 | |
| 6V9853 | 35 ELBOW | 1 | |
| 9X6458 | 36 WASHER-HARD (10.2X22.5X3-MM THK) | 3 |
