512-6906 MOUNTING GP-AIR CLEANERAN ATTACHMENT

Group No: 512-6906
Part NumberPart NameQty
16180711 HOSE AS2
31548412 BRACKET AS (RH)1
31548423 BRACKET AS (LH)1
1F0750NUT-WELD (3/8-16-THD)1
31548434 BRACKET AS2
1F0750NUT-WELD (3/8-16-THD)1
37709555 BRACKET2
37709566 BRACKET2
16539317 BOLT (3/8-16X1.75-IN)6
0S15888 BOLT (3/8-16X1.25-IN)8
0S15909 BOLT (3/8-16X2-IN)10
165392910 BOLT (3/8-16X1.5-IN)8
198476711 WASHER-HARD (13.5X30X12-MM THK)2
2A463912 BOLT (3/8-16X1.625-IN)8
2N128713 ELBOW-FLARED2
7J402614 ELBOW1
3J190715 SEAL-O-RING1
8M902416 WASHER-HARD (10.2X22.5X5-MM THK)8
8M912417 WASHER (10X22.5X8-MM THK)32
9S875218 NUT-FULL (3/8-16-THD)22
9X645819 WASHER-HARD (10.2X22.5X3-MM THK)22
2B094720 BOLT (1/2-13X2.25-IN)2
6V504821 SEAL-O-RING1
5P342622 ELBOW1
