System And Components
481-8249 WIRING GP-ENGINE -THERMOCOUPLEAN ATTACHMENT
Group No: 481-8249
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W8129 | 1 SUPPORT | 1 | |
| 5N2126 | 2 CONNECTOR (THERMOCOUPLE) | 16 | |
| 7K1181 | 3 STRAP-CABLE | 5 | |
| 9X3495 | 4 CLIP AS | 1 | |
| 9X6772 | 5 STRAP-CABLE | 21 | |
| 1113684 | 6 HOSE AS | 1 | |
| 1772215 | 7 STRAP-DUAL CLAMP | 1 | |
| 2123426 | 8 SENSOR GP-SPEED (ENGINE) | 1 | |
| 2298844 | 9 CLIP | 1 | |
| 2450522 | 10 BRACKET | 1 | |
| 2450523 | 11 BRACKET | 2 | |
| 2613856 | 12 BRACKET AS | 1 | |
| 7C2644 | CLIP | 1 | |
| 8C3334 | RIVET-TUBULAR | 2 | |
| 2616847 | 13 ADAPTER | 2 | |
| 2659033 | 14 SENSOR GP-SPEED (CRANKSHAFT POSITION) | 1 | |
| 2659033 | 14A SENSOR GP-SPEED (CAMSHAFT POSITION) | 1 | |
| 2694006 | 15 RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 8T8737 | PLUG-SEAL | 2 | |
| 2304012 | RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 2786469 | 16 GROMMET | 4 | |
| 2883783 | 17 SENSOR-TEMPERATURE (AIR INLET MANIFOLD, PRIMARY) | 1 | |
| 2883783 | 17A SENSOR-TEMPERATURE (AIR INLET MANIFOLD, SECONDARY) | 1 | |
| 2883783 | 17B SENSOR-TEMPERATURE (ENGINE COOLANT) | 1 | |
| 2883783 | 17C SENSOR-TEMPERATURE (SCAC) | 1 | |
| 2883783 | 17D SENSOR-TEMPERATURE (ENGINE OIL) | 1 | |
| 3011466 | 18 SPACER (11X21X54.5-MM THK) | 1 | |
| 3497374 | 19 SENSOR GP-PRESSURE (CRANKCASE) | 1 | |
| 3497374 | 19A SENSOR GP-PRESSURE (ATMOSPHERIC) | 1 | |
| 3497377 | 20 SENSOR GP-PRESSURE (AIR INLET MANIFOLD) | 2 | |
| 3535441 | 21 ADAPTER-ELBOW | 1 | |
| 3559605 | 22 ADAPTER | 2 | |
| 3664683 | 23 ADAPTER | 3 | |
| 3724759 | 24 BRACKET | 2 | |
| 3832990 | 25 SENSOR GP-TEMPERATURE (THERMOCOUPLE) | 16 | |
| 4152431 | 26 SENSOR GP-EXHAUST TEMPERATURE (3-PIN)(TURBOCHARGER INLET, LH) | 1 | |
| 4152431 | 26A SENSOR GP-EXHAUST TEMPERATURE (3-PIN)(TURBOCHARGER INLET, RH) | 1 | |
| 4683365 | 27 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 4818219 | 28 WIRING GP-ENGINE | 1 | |
| 4980255 | 29 BRACKET AS | 1 | |
| 9X2032 | NUT-WELD (M4X0.7-THD) | 2 | |
| 4991086 | 30 BRACKET | 1 | |
| 5028553 | 31 HARNESS GP-WIRING (RAIL, RH) | 1 | |
| 5028554 | 32 HARNESS GP-WIRING (RAIL, LH) | 1 | |
| 5043753 | 33 BRACKET AS | 1 | |
| 0019440 | 34 CONNECTOR | 1 | |
| 0L1143 | 35 BOLT (3/8-16X2.5-IN) | 1 | |
| 0L1351 | 36 BOLT (3/8-16X0.875-IN) | 1 | |
| 0S0509 | 37 BOLT (3/8-16X0.75-IN) | 3 | |
| 1653931 | 38 BOLT (3/8-16X1.75-IN) | 1 | |
| 0S1588 | 39 BOLT (3/8-16X1.25-IN) | 15 | |
| 0S1590 | 40 BOLT (3/8-16X2-IN) | 1 | |
| 1653929 | 41 BOLT (3/8-16X1.5-IN) | 5 | |
| 0S1594 | 42 BOLT (3/8-16X1-IN) | 16 | |
| 0S1608 | 43 BOLT (3/8-16X3.75-IN) | 1 | |
| 0S1619 | 44 BOLT (3/8-16X3-IN) | 4 | |
| 0S1621 | 45 BOLT (1/2-13X1-IN) | 1 | |
| 0T0065 | 46 BOLT (3/8-16X3.5-IN) | 1 | |
| 1153069 | 47 CLIP AS-CONNECTING (3-PIN) | 13 | |
| 1325789 | 48 CLIP (LADDER) | 6 | |
| 1391398 | 49 CLIP (LOOP) | 4 | |
| 1790469 | 50 SPACER (11X20X40-MM THK) | 1 | |
| 1984766 | 51 WASHER-HARD (11X25X10-MM THK) | 2 | |
| 2059920 | 52 STRAP-CABLE | 2 | |
| 2147566 | 53 SEAL-O-RING | 4 | |
| 2159632 | 54 SPACER (12X20X20-MM THK) | 2 | |
| 2190669 | 55 SEAL-O-RING | 2 | |
| 2287100 | 56 SEAL-O-RING | 5 | |
| 2287101 | 57 SEAL-O-RING | 2 | |
| 2385080 | 58 SEAL-O-RING | 1 | |
| 2856393 | 59 CLIP (LADDER) | 1 | |
| 2M3403 | 60 BOLT (3/8-16X3.63-IN) | 4 | |
| 3118802 | 61 SPACER (10.5X19X57-MM THK) | 4 | |
| 3309739 | 62 ADAPTER | 2 | |
| 3523965 | 63 CLIP (LADDER) | 1 | |
| 3523966 | 64 CLIP (LADDER) | 1 | |
| 3523968 | 65 CLIP (LADDER) | 1 | |
| 3535439 | 66 CONNECTOR | 1 | |
| 3K0360 | 67 SEAL-O-RING | 2 | |
| 4H1225 | 68 WASHER (11X22X6-MM THK) | 1 | |
| 4P7429 | 69 CLIP (LADDER) | 1 | |
| 4P7581 | 70 CLIP (LADDER) | 4 | |
| 4P8134 | 71 CLIP (LADDER) | 3 | |
| 5M2894 | 72 WASHER-HARD (10.2X18.5X2.5-MM THK) | 48 | |
| 5P2228 | 73 BOLT (1/2-13X1-IN) | 2 | |
| 5P3426 | 74 ELBOW | 1 | |
| 5P8245 | 75 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 6H1717 | 76 BOLT (1/2-13X1.125-IN) | 3 | |
| 6V1612 | 77 BOLT (1/2-13X9.75-IN) | 2 | |
| 6V5048 | 78 SEAL-O-RING | 1 | |
| 6V6609 | 79 SEAL-O-RING | 1 | |
| 7C4354 | 80 CLIP | 1 | |
| 7D1649 | 81 WASHER-HARD (13.5X32X5-MM THK) | 2 | |
| 7G5984 | 82 CLIP (TAB) | 4 | |
| 7G5985 | 83 CLIP (SLOT) | 4 | |
| 8M2770 | 84 CLIP (LOOP) | 2 | |
| 8T4223 | 85 WASHER-HARD (13.5X25.5X3-MM THK) | 5 | |
| 9M8406 | 86 CLIP (LOOP) | 3 | |
| 9S4185 | 87 PLUG (3/4-16-THD) | 1 | |
| 9S8752 | 88 NUT-FULL (3/8-16-THD) | 3 | |
| 9X6458 | 89 WASHER-HARD (10.2X22.5X3-MM THK) | 8 |
