System And Components
398-3766 FILTER GP-ENGINE OILS/N MLX1-UP
Group No: 398-3766
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4712751 | 1 SPRING | 1 | |
| 1P1367 | 2 PLUNGER (RELIEF VALVE)(OIL COOLER) | 4 | |
| 2W1053 | 3 PLUG | 1 | |
| 2W1969 | 4 VALVE-BYPASS (OIL COOLER) | 1 | |
| 6B9202 | 5 SPRING | 2 | |
| 7G6713 | 6 SPRING-MAIN | 4 | |
| 7N7697 | 7 PLUNGER AS | 2 | |
| 7M1808 | DOWEL | 1 | |
| 8N1991 | 8 RING-RETAINING | 1 | |
| 8N1992 | 9 RETAINER | 2 | |
| 8N2929 | 10 COVER | 1 | |
| 1008075 | 11 CLAMP AS | 1 | |
| 1113820 | 12 RING-RETAINING | 2 | |
| 1116119 | 13 SHIELD | 4 | |
| 1119373 | 14 CLAMP AS | 1 | |
| 1363296 | 15 FLANGE | 1 | |
| 1467359 | 16 TUBE | 1 | |
| 1506612 | 17 ELBOW-OUTLET | 1 | |
| 1519270 | 18 BASE AS-OIL FILTER | 2 | |
| 4852866 | STUD (1-1/2-12X3-IN) | 2 | |
| 1539963 | 19 RING | 2 | |
| 2147568 | 20 SEAL-O-RING | 1 | |
| 2377623 | 21 SEAL-O-RING | 2 | |
| 2445867 | 22 ELBOW (OIL COOLER BYPASS) | 1 | |
| 2456848 | 23 CLAMP AS | 4 | |
| 2474806 | 24 ELBOW | 1 | |
| 2640450 | 25 CLAMP AS | 2 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 2 | |
| 2752604 | 26 FILTER-ENGINE OIL (ADVANCED EFFICIENCY) | 4 | |
| 3116130 | 27 SEAL-O-RING | 1 | |
| 3594122 | 28 ELBOW | 1 | |
| 3594123 | 29 ADAPTER | 1 | |
| 3617097 | 30 RING | 1 | |
| 3617098 | 31 FLANGE | 1 | |
| 4162252 | 32 TUBE | 1 | |
| 4230914 | 33 TUBE | 1 | |
| 4230915 | 34 ELBOW | 1 | |
| 4309132 | 35 COVER | 1 | |
| 5221082 | 36 ADAPTER-BASE | 2 | |
| 0L1143 | 37 BOLT (3/8-16X2.5-IN) | 4 | |
| 1653931 | 38 BOLT (3/8-16X1.75-IN) | 8 | |
| 1653928 | 39 BOLT (3/8-16-THD) | 8 | |
| 1653929 | 40 BOLT (3/8-16X1.5-IN) | 23 | |
| 0S1594 | 41 BOLT (3/8-16X1-IN) | 8 | |
| 0T0065 | 42 BOLT (3/8-16X3.5-IN) | 4 | |
| 1092332 | 43 SEAL-O-RING | 4 | |
| 1A2029 | 44 BOLT (3/8-16X1.125-IN) | 10 | |
| 1A5964 | 45 BOLT (3/8-16X4.5-IN) | 2 | |
| 1S7106 | 46 COVER | 4 | |
| 2287097 | 47 SEAL-O-RING | 1 | |
| 2B2695 | 48 BOLT (5/16-18X0.875-IN) | 8 | |
| 2697885 | 49 SEAL-O-RING | 1 | |
| 3S1546 | 50 NUT-FULL (7/16-14-THD) | 4 | |
| 4B3140 | 51 COVER | 1 | |
| 4F8965 | 52 BOLT (7/16-14X1.125-IN) | 4 | |
| 4P7581 | 53 CLIP (LADDER) | 2 | |
| 5M2894 | 54 WASHER-HARD (10.2X18.5X2.5-MM THK) | 22 | |
| 5P4892 | 55 SEAL-O-RING | 1 | |
| 5P5846 | 56 SEAL-O-RING | 1 | |
| 5P8244 | 57 WASHER-HARD (12X22.5X2.5-MM THK) | 8 | |
| 6B0933 | 58 SPACER (10.31X19.05X6.35-MM THK) | 4 | |
| 6J2244 | 59 SEAL-O-RING | 1 | |
| 6V3908 | 60 SEAL-O-RING | 1 | |
| 4477206 | 61 SEAL-O-RING | 4 | |
| 1367227 | 62 SEAL-O-RING | 1 | |
| 6V5048 | 63 SEAL-O-RING | 4 | |
| 2385080 | 64 SEAL-O-RING | 1 | |
| 7F9090 | 65 SCREW-DRIVE (NO 8X3/8-IN) | 8 | |
| 8C3107 | 66 SEAL-O-RING | 1 | |
| 8C3445 | 67 CAP-DUST | 1 | |
| 8C3446 | 68 VALVE-SAMPLING (ENGINE OIL) | 1 | |
| 8C6427 | 69 ADAPTER | 1 | |
| 8T6758 | 70 PLUG-PIPE (1/4-18-THD) | 1 | |
| 8T6762 | 71 PLUG-PIPE (1/2-14-THD) | 2 | |
| 9M1974 | 72 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 9S4182 | 73 PLUG (7/16-20-THD) | 3 | |
| 9S4185 | 74 PLUG (3/4-16-THD) | 1 | |
| 9S4190 | 75 PLUG-O-RING (7/8-14-THD) | 1 | |
| 9S8004 | 76 PLUG (9/16-18-THD) | 1 | |
| 9S8752 | 77 NUT-FULL (3/8-16-THD) | 17 | |
| 9X6458 | 78 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 9Y8387 | 79 GASKET | 4 | |
| 9Y8388 | 80 GASKET | 3 |
