System And Components
492-2159 LINES GP-OIL -SCACS/N MLX1-UP
Group No: 492-2159
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1013120 | 1 SPACER (10.5X25X20-MM THK) | 1 | |
| 2815977 | 2 CONNECTOR AS | 1 | |
| 6V8642 | CONNECTOR | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 4197200 | 3 HOSE & TUBE AS | 1 | |
| 4206834 | 4 MANIFOLD | 1 | |
| 4391826 | 5 CONNECTOR AS | 1 | |
| 6V8647 | CONNECTOR | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 2287088 | SEAL-O-RING | 1 | |
| 4789319 | 6 HOSE AS-OIL | 1 | |
| 4810291 | 7 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 4921719 | 8 TUBE AS | 1 | |
| 0L2070 | 9 BOLT (3/8-16X2.25-IN) | 1 | |
| 1653931 | 10 BOLT (3/8-16X1.75-IN) | 5 | |
| 0S1594 | 11 BOLT (3/8-16X1-IN) | 1 | |
| 0S1621 | 12 BOLT (1/2-13X1-IN) | 1 | |
| 1833399 | 13 CONNECTOR AS | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 1949625 | 14 WASHER-HARD (13.5X18X4-MM THK) | 1 | |
| 2287088 | 15 SEAL-O-RING | 1 | |
| 2815975 | 16 ELBOW AS | 1 | |
| 6V8626 | ELBOW | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3256994 | 17 CLIP (SLOT) | 2 | |
| 3256995 | 18 CLIP (TAB) | 2 | |
| 3537956 | 19 GROMMET | 2 | |
| 5M2894 | 20 WASHER-HARD (10.2X18.5X2.5-MM THK) | 5 | |
| 6V4367 | 21 SEAL-O-RING | 1 | |
| 9X6458 | 22 WASHER-HARD (10.2X22.5X3-MM THK) | 1 |
