System And Components
396-8170 BATTERY & MOUNTING GPS/N MLX1-UP
Group No: 396-8170
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V9197 | 1 LOCK PIN | 2 | |
| 9M3835 | 2 LATCH-RUBBER | 2 | |
| 1343123 | 3 BRACKET AS (BATTERY HOLD-DOWN) | 1 | |
| 1526065 | 4 BATTERY (12-VOLT) | 2 | |
| 3968149 | 5 BOX AS-BATTERY | 1 | |
| 3968151 | 6 COVER AS (BATTERY) | 1 | |
| 8P0612 | BRACKET | 2 | |
| 3968152 | 7 BRACKET AS (BREAKER PANEL) | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 2 | |
| 1K6872 | 8 LOCKNUT (1/2-13-THD) | 6 | |
| 2K4973 | 9 LOCKNUT (3/8-16-THD) | 1 | |
| 2M5795 | 10 PIN-CLEVIS | 2 | |
| 4H3283 | 11 BOLT (3/8-16X9.5-IN) | 2 | |
| 4L6454 | 12 BOLT (3/8-16X1-IN) | 3 | |
| 5P1075 | 13 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 5P1076 | 14 WASHER-HARD (13.5X30X4-MM THK) | 6 | |
| 6V8801 | 15 NUT (3/8-16-THD) | 2 | |
| 8T4223 | 16 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 8T4835 | 17 BOLT (1/2-13X2-IN) | 6 | |
| 8T4896 | 18 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 |
