System And Components
542-7370 GUARDRAIL GPS/N MLX1-UP
Group No: 542-7370
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2G9399 | 1 ROD | 1 | |
| 3672481 | 2 CAP | 2 | |
| 5395449 | 3 PLATE-LATCH | 1 | |
| 5395450 | 4 PLATE-COVER | 1 | |
| 5395451 | 5 HANDRAIL AS | 1 | |
| 5395454 | 6 PLATE-STOP | 1 | |
| 5395455 | 7 GATE AS | 1 | |
| 5427369 | 8 HANDRAIL AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 2 | |
| 5262156 | HINGE AS | 2 | |
| 1K6872 | 9 LOCKNUT (1/2-13-THD) | 10 | |
| 3B4615 | 10 PIN-COTTER | 1 | |
| 4L6454 | 11 BOLT (3/8-16X1-IN) | 4 | |
| 5P1075 | 12 WASHER-HARD (10.2X22.5X3-MM THK) | 11 | |
| 5P1076 | 13 WASHER-HARD (13.5X30X4-MM THK) | 10 | |
| 6C3241 | 14 BOLT (1/2-13X1.5-IN) | 10 | |
| 5S7379 | 15 BOLT (3/8-16X0.875-IN) | 7 | |
| 6F8499 | 16 SPRING | 1 | |
| 6V8801 | 17 NUT (3/8-16-THD) | 2 | |
| 7X0605 | 18 WASHER-HARD (13X28X1.6-MM THK) | 1 | |
| 8T4223 | 19 WASHER-HARD (13.5X25.5X3-MM THK) | 10 | |
| 8T4896 | 20 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 3E8349 | 21 SEAL (6-CM EACH) |
