System And Components
532-6245 RAILING & PLATFORM GP -REARS/N MLX1-UP
Group No: 532-6245
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3358947 | 1 CLIP | 9 | |
| 5326239 | 2 PLATE | 1 | |
| 5326240 | 3 PLATE AS | 1 | |
| 5326241 | 4 BRACKET | 3 | |
| 5326242 | 5 PLATFORM | 1 | |
| 5326243 | 6 HANDRAIL AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 4 | |
| 5326244 | 7 HANDRAIL AS | 1 | |
| 1K6872 | 8 LOCKNUT (1/2-13-THD) | 16 | |
| 2D6235 | 9 LOCKNUT (1/4-20-THD) | 9 | |
| 5P1075 | 10 WASHER-HARD (10.2X22.5X3-MM THK) | 4 | |
| 5P1076 | 11 WASHER-HARD (13.5X30X4-MM THK) | 22 | |
| 5P2424 | 12 BOLT (1/2-13X2.25-IN) | 2 | |
| 6C3241 | 13 BOLT (1/2-13X1.5-IN) | 10 | |
| 5P4115 | 14 WASHER-HARD (7.2X19X2-MM THK) | 9 | |
| 5S7379 | 15 BOLT (3/8-16X0.875-IN) | 4 | |
| 7X3178 | 16 BOLT (1/4-20X1.625-IN) | 9 | |
| 8T4205 | 17 WASHER-HARD (7.2X14.5X2-MM THK) | 9 | |
| 8T4223 | 18 WASHER-HARD (13.5X25.5X3-MM THK) | 10 | |
| 8T8919 | 19 BOLT (1/2-13X1.75-IN) | 4 |
